Specifications: Opel Astra F Classic (facelift 1994) 1.8i Ecotec 16V (116 Hp) 1994, 1995

1994 Opel Astra F Classic (facelift 1994) - Photo 1

Opel Astra F Classic (facelift 1994) 1.8i Ecotec 16V (116 Hp) – Full specifications
General information
Brand Opel
Model Astra
Generation Astra F Classic (facelift 1994)
Modification (Engine) 1.8i Ecotec 16V (116 Hp)
Start of production August, 1994 year
End of production April, 1995 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 11.1 l/100 km
21.19 US mpg
25.45 UK mpg
9.01 km/l
Fuel consumption (economy) – extra urban 7.5 l/100 km
31.36 US mpg
37.66 UK mpg
13.33 km/l
Fuel consumption (economy) – combined 9.7 l/100 km
24.25 US mpg
29.12 UK mpg
10.31 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.5 sec
Acceleration 0 – 62 mph 9.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9 sec
Maximum speed 200 km/h
124.27 mph
Weight-to-power ratio 9.6 kg/Hp, 104 Hp/tonne
Weight-to-torque ratio 6.6 kg/Nm, 150.7 Nm/tonne
Engine specs
Power 116 Hp @ 5400 rpm.
Power per litre 64.5 Hp/l
Torque 168 Nm @ 4000 rpm.
123.91 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code C18XEL
Engine displacement 1799 cm3
109.78 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81.6 mm
3.21 in.
Piston Stroke 86 mm
3.39 in.
Compression ratio 10.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt

Space, Volume and weights
Kerb Weight 1115 kg
2458.15 lbs.
Max. weight 1595 kg
3516.37 lbs.
Max load 480 kg
1058.22 lbs.
Trunk (boot) space – minimum 500 l
17.66 cu. ft.
Trunk (boot) space – maximum 1200 l
42.38 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Dimensions
Length 4239 mm
166.89 in.
Width 1696 mm
66.77 in.
Width including mirrors 1852 mm
72.91 in.
Height 1410 mm
55.51 in.
Wheelbase 2517 mm
99.09 in.
Front track 1424 mm
56.06 in.
Rear (Back) track 1423 mm
56.02 in.
Ride height (ground clearance) 135 mm
5.31 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.5 m
34.45 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Steering type Steering rack and pinion
Tires size 175/65 R14 82H
Wheel rims size 5.5J x 14
