Specifications: Opel Astra G (facelift 2002) 1.8 16V (125 Hp) 2002, 2003, 2004

2002 Opel Astra G (facelift 2002) - Photo 1

Opel Astra G (facelift 2002) 1.8 16V (125 Hp) – Full specifications
General information
Brand Opel
Model Astra
Generation Astra G (facelift 2002)
Modification (Engine) 1.8 16V (125 Hp)
Start of production 2002 year
End of production February, 2004 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3-5
Performance specs
Fuel consumption (economy) – urban 11 l/100 km
21.38 US mpg
25.68 UK mpg
9.09 km/l
Fuel consumption (economy) – extra urban 6.1 l/100 km
38.56 US mpg
46.31 UK mpg
16.39 km/l
Fuel consumption (economy) – combined 7.8 l/100 km
30.16 US mpg
36.22 UK mpg
12.82 km/l
CO2 emissions 187 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.5 sec
Acceleration 0 – 62 mph 9.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9 sec
Maximum speed 205 km/h
127.38 mph
Weight-to-power ratio 9.1 kg/Hp, 110.1 Hp/tonne
Weight-to-torque ratio 6.7 kg/Nm, 149.8 Nm/tonne
Engine specs
Power 125 Hp @ 5600 rpm.
Power per litre 69.6 Hp/l
Torque 170 Nm @ 3800 rpm.
125.39 lb.-ft. @ 3800 rpm.
Engine layout Front, Transverse
Engine Model/Code Z18XE
Engine displacement 1796 cm3
109.6 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80.5 mm
3.17 in.
Piston Stroke 88.2 mm
3.47 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.25 l
4.49 US qt | 3.74 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.3 l
6.66 US qt | 5.54 UK qt

Space, Volume and weights
Kerb Weight 1135 kg
2502.25 lbs.
Max. weight 1680 kg
3703.77 lbs.
Max load 545 kg
1201.52 lbs.
Trunk (boot) space – minimum 370 l
13.07 cu. ft.
Trunk (boot) space – maximum 1180 l
41.67 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Dimensions
Length 4110 mm
161.81 in.
Width 1709 mm
67.28 in.
Width including mirrors 1967 mm
77.44 in.
Height 1425 mm
56.1 in.
Wheelbase 2606 mm
102.6 in.
Front track 1464 mm
57.64 in.
Rear (Back) track 1452 mm
57.17 in.
Front overhang 791 mm
31.14 in.
Rear overhang 713 mm
28.07 in.
Ride height (ground clearance) 160 mm
6.3 in.
Drag coefficient (Cd) 0.32
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Wishbone
Rear suspension Suspension with traction connecting levers
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/60 R15
Wheel rims size 15
