| General information | |
|---|---|
| Brand | Opel |
| Model | Grandland |
| Generation | Grandland (facelift 2021) |
| Modification (Engine) | GSe 1.6i Turbo (300 Hp) Plug-in Hybrid4 AWD Automatic |
| Start of production | July, 2021 year |
| End of production | September, 2024 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 1.2-1.7 l/100 km 196.01 – 138.36 US mpg 235.4 – 166.17 UK mpg 83.33 – 58.82 km/l |
| CO2 emissions (WLTP) | 28-39 g/km |
| Fuel consumption (economy) – combined (NEDC, WLTP equivalent) | 1.5-1.6 l/100 km 156.81 – 147.01 US mpg 188.32 – 176.55 UK mpg 66.67 – 62.5 km/l |
| CO2 emissions (NEDC, WLTP equivalent) | 33-37 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 6.1 sec |
| Acceleration 0 – 62 mph | 6.1 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 5.8 sec |
| Maximum speed | 235 km/h 146.02 mph |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 6 kg/Hp, 166.6 Hp/tonne |
| Weight-to-torque ratio | 3.5 kg/Nm, 288.7 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 13.2 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| All-electric range (WLTP) | 55-65 km 34.18 – 40.39 mi |
| All-electric range (NEDC, WLTP equivalent) | 67-69 km 41.63 – 42.87 mi |
| Average Energy consumption (WLTP) | 14.9-17.4 kWh/100 km
23.98 – 28 kWh/100 mi |
| Max speed (electric) | 135 km/h
83.89 mph |
| Electric motor 1 | |
| Electric motor power | 110 Hp @ 2500 rpm. |
| Electric motor Torque | 320 Nm @ 500-2500 rpm.
236.02 lb.-ft. @ 500-2500 rpm. |
| Electric motor location | Between the combustion engine and the transmission |
| Electric motor 2 | |
| Electric motor power | 113 Hp @ 14000 rpm. |
| Electric motor Torque | 166 Nm @ 0-4760 rpm.
122.44 lb.-ft. @ 0-4760 rpm. |
| Electric motor location | Rear axle, Transverse |
| System power | 300 Hp |
| System torque | 520 Nm 383.53 lb.-ft. |
| Internal combustion engine specs | |
| Power | 200 Hp @ 6000 rpm. |
| Power per litre | 125.2 Hp/l |
| Torque | 300 Nm @ 3000 rpm. 221.27 lb.-ft. @ 3000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | F16XHR |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 4.25 l 4.49 US qt | 3.74 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1801 kg 3970.53 lbs. |
| Max. weight | 2370 kg 5224.96 lbs. |
| Max load | 569 kg 1254.43 lbs. |
| Trunk (boot) space – minimum | 390 l 13.77 cu. ft. |
| Trunk (boot) space – maximum | 1528 l 53.96 cu. ft. |
| Fuel tank capacity | 43 l 11.36 US gal | 9.46 UK gal |
| Max. roof load | 85 kg 187.39 lbs. |
| Permitted trailer load with brakes (12%) | 1250 kg 2755.78 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 70 kg 154.32 lbs. |
| Dimensions | |
| Length | 4477 mm 176.26 in. |
| Width | 1906 mm 75.04 in. |
| Width including mirrors | 2098 mm 82.6 in. |
| Height | 1609 mm 63.35 in. |
| Wheelbase | 2675 mm 105.31 in. |
| Front track | 1579-1595 mm 62.17 – 62.8 in. |
| Rear (Back) track | 1587-1610 mm 62.48 – 63.39 in. |
| Front overhang | 933 mm 36.73 in. |
| Rear overhang | 869 mm 34.21 in. |
| Minimum turning circle (turning diameter) | 10.67 m 35.01 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/55 R18; 205/55 R19 |
| Wheel rims size | 7.5J x 18; 7J x 19 |
