Specifications: Opel Insignia Hatchback (A) 2.0 Turbo (250 Hp) 2011, 2012, 2013

2009 Opel Insignia Hatchback (A) - Photo 1

Opel Insignia Hatchback (A) 2.0 Turbo (250 Hp) – Full specifications
General information
Brand Opel
Model Insignia
Generation Insignia Hatchback (A)
Modification (Engine) 2.0 Turbo (250 Hp)
Start of production July, 2011 year
End of production June, 2013 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 10.1 l/100 km
23.29 US mpg
27.97 UK mpg
9.9 km/l
Fuel consumption (economy) – extra urban 5.5 l/100 km
42.77 US mpg
51.36 UK mpg
18.18 km/l
Fuel consumption (economy) – combined 7.2 l/100 km
32.67 US mpg
39.23 UK mpg
13.89 km/l
CO2 emissions 169 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.6 sec
Acceleration 0 – 62 mph 7.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.2 sec
Maximum speed 242 km/h
150.37 mph
Emission standard Euro 5
Weight-to-power ratio 6.9 kg/Hp, 144.3 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 230.8 Nm/tonne
Engine specs
Power 250 Hp @ 5300 rpm.
Power per litre 125.1 Hp/l
Torque 400 Nm @ 2400-3600 rpm.
295.02 lb.-ft. @ 2400-3600 rpm.
Engine layout Front, Transverse
Engine Model/Code A20NFT
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 86 mm
3.39 in.
Compression ratio 9.3:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Twin-scroll turbo, Intercooler
Engine oil capacity 5.7 l
6.02 US qt | 5.02 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.8 l
8.24 US qt | 6.86 UK qt

Space, Volume and weights
Kerb Weight 1733 kg
3820.61 lbs.
Max. weight 2250 kg
4960.4 lbs.
Max load 517 kg
1139.79 lbs.
Trunk (boot) space – minimum 520 l
18.36 cu. ft.
Trunk (boot) space – maximum 1465 l
51.74 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4830 mm
190.16 in.
Width 1858 mm
73.15 in.
Height 1498 mm
58.98 in.
Wheelbase 2737 mm
107.76 in.
Front track 1585 mm
62.4 in.
Rear (Back) track 1587 mm
62.48 in.
Ride height (ground clearance) 160 mm
6.3 in.
Minimum turning circle (turning diameter) 10.8 m
35.43 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Tires size 225/55 R17
Wheel rims size 17
