Specifications: Opel Insignia Sports Tourer (B) 1.6 Turbo (200 Hp) Automatic 2018, 2019

2017 Opel Insignia Sports Tourer (B) - Photo 1

Opel Insignia Sports Tourer (B) 1.6 Turbo (200 Hp) Automatic – Full specifications
General information
Brand Opel
Model Insignia
Generation Insignia Sports Tourer (B)
Modification (Engine) 1.6 Turbo (200 Hp) Automatic
Start of production June, 2018 year
End of production September, 2019 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 8.1-8.3 l/100 km
29.04 – 28.34 US mpg
34.87 – 34.03 UK mpg
12.35 – 12.05 km/l
Fuel consumption (economy) – extra urban 5.5-5.8 l/100 km
42.77 – 40.55 US mpg
51.36 – 48.7 UK mpg
18.18 – 17.24 km/l
Fuel consumption (economy) – combined 6.4-6.7 l/100 km
36.75 – 35.11 US mpg
44.14 – 42.16 UK mpg
15.63 – 14.93 km/l
CO2 emissions 147-154 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.2 sec
Acceleration 0 – 62 mph 8.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.8 sec
Maximum speed 230 km/h
142.92 mph
Emission standard Euro 6d-Temp
Weight-to-power ratio 7.4 kg/Hp, 135.4 Hp/tonne
Weight-to-torque ratio 5.3 kg/Nm, 189.6 Nm/tonne
Engine specs
Power 200 Hp @ 5500 rpm.
Power per litre 125.2 Hp/l
Torque 280 Nm @ 1650-4500 rpm.
206.52 lb.-ft. @ 1650-4500 rpm.
Engine layout Front, Transverse
Engine Model/Code D16SHT
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79 mm
3.11 in.
Piston Stroke 81.5 mm
3.21 in.
Compression ratio 9.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1477 kg
3256.23 lbs.
Max. weight 2165 kg
4773.01 lbs.
Max load 688 kg
1516.78 lbs.
Trunk (boot) space – minimum 560 l
19.78 cu. ft.
Trunk (boot) space – maximum 1660 l
58.62 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 1450 kg
3196.7 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4986 mm
196.3 in.
Width 1863 mm
73.35 in.
Width with mirrors folded 1941 mm
76.42 in.
Width including mirrors 2093 mm
82.4 in.
Height 1500 mm
59.06 in.
Wheelbase 2829 mm
111.38 in.
Front track 1607 mm
63.27 in.
Rear (Back) track 1610 mm
63.39 in.
Front overhang 990 mm
38.98 in.
Rear overhang 1167 mm
45.94 in.
Minimum turning circle (turning diameter) 11.74 m
38.52 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/60 R16; 215/55 R17; 225/55 R17; 245/45 R18
Wheel rims size 6.5J x 16; 7J x 17; 7.5J x 17; 8.5J x 18
