Specifications: Opel Signum 2.2 DTI ECOTEC (125 Hp) Automatic 2003, 2004

2003 Opel Signum - Photo 1

Opel Signum 2.2 DTI ECOTEC (125 Hp) Automatic – Full specifications
General information
Brand Opel
Model Signum
Generation Signum
Modification (Engine) 2.2 DTI ECOTEC (125 Hp) Automatic
Start of production May, 2003 year
End of production November, 2004 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC) 10.5-10.6 l/100 km
22.4 – 22.19 US mpg
26.9 – 26.65 UK mpg
9.52 – 9.43 km/l
Fuel consumption (economy) – extra urban (NEDC) 5.6-5.7 l/100 km
42 – 41.27 US mpg
50.44 – 49.56 UK mpg
17.86 – 17.54 km/l
Fuel consumption (economy) – combined (NEDC) 7.4-7.5 l/100 km
31.79 – 31.36 US mpg
38.17 – 37.66 UK mpg
13.51 – 13.33 km/l
CO2 emissions (NEDC) 200-203 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 12.2 sec
Acceleration 0 – 62 mph 12.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.6 sec
Maximum speed 198 km/h
123.03 mph
Emission standard Euro 3
Engine specs
Power 125 Hp @ 3250 rpm.
Power per litre 57.6 Hp/l
Torque 280 Nm @ 1500-3000 rpm.
206.52 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code Y22DTR
Engine displacement 2171 cm3
132.48 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 98 mm
3.86 in.
Compression ratio 18.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.8 l
8.24 US qt | 6.86 UK qt

Space, Volume and weights
Trunk (boot) space – minimum 875 l
30.9 cu. ft.
Trunk (boot) space – maximum 1410 l
49.79 cu. ft.
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 1800 kg
3968.32 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4636 mm
182.52 in.
Width 1798 mm
70.79 in.
Width including mirrors 2036 mm
80.16 in.
Height 1466 mm
57.72 in.
Wheelbase 2830 mm
111.42 in.
Front track 1536 mm
60.47 in.
Rear (Back) track 1525 mm
60.04 in.
Minimum turning circle (turning diameter) 11.92 m
39.11 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Independent type McPherson, Transverse stabilizer
Rear suspension Independent multi-link suspension, Transverse stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/55 R16; 215/50 R17
Wheel rims size 6.5J x 16; 7J x 17
