Specifications: Opel Vectra A (facelift 1992) 1.6i CAT (75 Hp) 1992, 1993

1992 Opel Vectra A (facelift 1992) - Photo 1

Opel Vectra A (facelift 1992) 1.6i CAT (75 Hp) – Full specifications
General information
Brand Opel
Model Vectra
Generation Vectra A (facelift 1992)
Modification (Engine) 1.6i CAT (75 Hp)
Start of production August, 1992 year
End of production November, 1993 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – combined 7 l/100 km
33.6 US mpg
40.35 UK mpg
14.29 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 14 sec
Acceleration 0 – 62 mph 14 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 13.3 sec
Maximum speed 176 km/h
109.36 mph
Weight-to-power ratio 14.9 kg/Hp, 67.3 Hp/tonne
Weight-to-torque ratio 9.3 kg/Nm, 107.6 Nm/tonne
Engine specs
Power 75 Hp @ 5400 rpm.
Power per litre 46.9 Hp/l
Torque 120 Nm @ 2800 rpm.
88.51 lb.-ft. @ 2800 rpm.
Engine layout Front, Transverse
Engine Model/Code C16NZ
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80 mm
3.15 in.
Piston Stroke 79.5 mm
3.13 in.
Compression ratio 8.8:1
Number of valves per cylinder 2
Fuel injection system Single-point injection
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 3.5 l
3.7 US qt | 3.08 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.8 l
6.13 US qt | 5.1 UK qt

Space, Volume and weights
Kerb Weight 1115 kg
2458.15 lbs.
Max. weight 1630 kg
3593.53 lbs.
Max load 515 kg
1135.38 lbs.
Trunk (boot) space – minimum 530 l
18.72 cu. ft.
Trunk (boot) space – maximum 840 l
29.66 cu. ft.
Fuel tank capacity 61 l
16.11 US gal | 13.42 UK gal
Dimensions
Length 4432 mm
174.49 in.
Width 1706 mm
67.17 in.
Height 1400 mm
55.12 in.
Wheelbase 2600 mm
102.36 in.
Front track 1420 mm
55.91 in.
Rear (Back) track 1423 mm
56.02 in.
Drag coefficient (Cd) 0.29
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front brakes Disc
Rear brakes Drum
Tires size 175/70 R14
Wheel rims size 14
