Specifications: Opel Vectra C Caravan 3.0i V6 24V CDTI (177 Hp) Automatic 2003, 2004, 2005

2003 Opel Vectra C Caravan - Photo 1

Opel Vectra C Caravan 3.0i V6 24V CDTI (177 Hp) Automatic – Full specifications
General information
Brand Opel
Model Vectra
Generation Vectra C Caravan
Modification (Engine) 3.0i V6 24V CDTI (177 Hp) Automatic
Start of production July, 2003 year
End of production June, 2005 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 11 l/100 km
21.38 US mpg
25.68 UK mpg
9.09 km/l
Fuel consumption (economy) – extra urban 5.8 l/100 km
40.55 US mpg
48.7 UK mpg
17.24 km/l
Fuel consumption (economy) – combined 7.7 l/100 km
30.55 US mpg
36.69 UK mpg
12.99 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.1 sec
Acceleration 0 – 62 mph 10.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.6 sec
Maximum speed 220 km/h
136.7 mph
Weight-to-power ratio 9.6 kg/Hp, 103.8 Hp/tonne
Weight-to-torque ratio 4.6 kg/Nm, 217 Nm/tonne
Engine specs
Power 177 Hp @ 4000 rpm.
Power per litre 59.8 Hp/l
Torque 370 Nm @ 1900 rpm.
272.9 lb.-ft. @ 1900 rpm.
Engine layout Front, Transverse
Engine Model/Code Y30DT
Engine displacement 2958 cm3
180.51 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 87.5 mm
3.44 in.
Piston Stroke 82 mm
3.23 in.
Compression ratio 18.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 7.5 l
7.93 US qt | 6.6 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.3 l
8.77 US qt | 7.3 UK qt

Space, Volume and weights
Kerb Weight 1705 kg
3758.88 lbs.
Max. weight 2240 kg
4938.35 lbs.
Max load 535 kg
1179.47 lbs.
Trunk (boot) space – minimum 530 l
18.72 cu. ft.
Trunk (boot) space – maximum 1850 l
65.33 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4822 mm
189.84 in.
Width 1798 mm
70.79 in.
Height 1500 mm
59.06 in.
Wheelbase 2830 mm
111.42 in.
Front track 1536 mm
60.47 in.
Rear (Back) track 1525 mm
60.04 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Spring Strut
Rear suspension Several levers and rods
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 215/55 R16
Wheel rims size 6.5J X 16
