Specifications: Opel Zafira B 1.6i 16V (105 Hp) 2005, 2006

2006 Opel Zafira B - Photo 1

Opel Zafira B 1.6i 16V (105 Hp) – Full specifications
General information
Brand Opel
Model Zafira
Generation Zafira B
Modification (Engine) 1.6i 16V (105 Hp)
Start of production July, 2005 year
End of production October, 2006 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.4 l/100 km
25.02 US mpg
30.05 UK mpg
10.64 km/l
Fuel consumption (economy) – extra urban 6.1 l/100 km
38.56 US mpg
46.31 UK mpg
16.39 km/l
Fuel consumption (economy) – combined 7.3 l/100 km
32.22 US mpg
38.7 UK mpg
13.7 km/l
CO2 emissions 170 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 14.3 sec
Acceleration 0 – 62 mph 14.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 13.6 sec
Maximum speed 176 km/h
109.36 mph
Emission standard Euro 4
Weight-to-power ratio 14.3 kg/Hp, 69.8 Hp/tonne
Weight-to-torque ratio 10 kg/Nm, 99.7 Nm/tonne
Engine specs
Power 105 Hp @ 6000 rpm.
Power per litre 65.7 Hp/l
Torque 150 Nm @ 3900 rpm.
110.63 lb.-ft. @ 3900 rpm.
Engine layout Front, Transverse
Engine Model/Code Z16XEP
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79 mm
3.11 in.
Piston Stroke 81.5 mm
3.21 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.1 l
6.45 US qt | 5.37 UK qt

Space, Volume and weights
Kerb Weight 1505 kg
3317.96 lbs.
Max. weight 2075 kg
4574.59 lbs.
Max load 570 kg
1256.63 lbs.
Trunk (boot) space – minimum 140 l
4.94 cu. ft.
Trunk (boot) space – maximum 1820 l
64.27 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
Dimensions
Length 4467 mm
175.87 in.
Width 1801 mm
70.91 in.
Height 1645 mm
64.76 in.
Wheelbase 2703 mm
106.42 in.
Front track 1488 mm
58.58 in.
Rear (Back) track 1510 mm
59.45 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Spring Strut
Rear suspension Torsion
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16
Wheel rims size 6.5J X 16
