Specifications: Opel Zafira Tourer C (facelift 2016) 1.4 Turbo ecoFLEX (140 Hp) 7 Seat 2016, 2017

2017 Opel Zafira Tourer C (facelift 2016) - Photo 1

Opel Zafira Tourer C (facelift 2016) 1.4 Turbo ecoFLEX (140 Hp) 7 Seat – Full specifications
General information
Brand Opel
Model Zafira
Generation Zafira Tourer C (facelift 2016)
Modification (Engine) 1.4 Turbo ecoFLEX (140 Hp) 7 Seat
Start of production June, 2016 year
End of production June, 2017 year
Powertrain Architecture Internal Combustion engine
Body type MPV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.6-8.0 l/100 km
30.95 – 29.4 US mpg
37.17 – 35.31 UK mpg
13.16 – 12.5 km/l
Fuel consumption (economy) – extra urban 5.3-5.6 l/100 km
44.38 – 42 US mpg
53.3 – 50.44 UK mpg
18.87 – 17.86 km/l
Fuel consumption (economy) – combined 6.1-6.5 l/100 km
38.56 – 36.19 US mpg
46.31 – 43.46 UK mpg
16.39 – 15.38 km/l
CO2 emissions 152-144 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.7 sec
Acceleration 0 – 62 mph 10.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.2 sec
Maximum speed 202 km/h
125.52 mph
Emission standard Euro 6
Weight-to-power ratio 11.3 kg/Hp, 88.6 Hp/tonne
Weight-to-torque ratio 7.9 kg/Nm, 126.6 Nm/tonne
Engine specs
Power 140 Hp @ 4900-6000 rpm.
Power per litre 102.6 Hp/l
Torque 200 Nm @ 1850-4900 rpm.
147.51 lb.-ft. @ 1850-4900 rpm.
Engine layout Front, Transverse
Engine Model/Code B14NET
Engine displacement 1364 cm3
83.24 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 72.5 mm
2.85 in.
Piston Stroke 82.6 mm
3.25 in.
Compression ratio 9.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.2 l
6.55 US qt | 5.46 UK qt

Space, Volume and weights
Kerb Weight 1580 kg
3483.3 lbs.
Max. weight 2320 kg
5114.72 lbs.
Max load 740 kg
1631.42 lbs.
Trunk (boot) space – minimum 152 l
5.37 cu. ft.
Trunk (boot) space – maximum 1792 l
63.28 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 1300 kg
2866.01 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4666 mm
183.7 in.
Width 1884 mm
74.17 in.
Width with mirrors folded 1928 mm
75.91 in.
Width including mirrors 2100 mm
82.68 in.
Height 1660 mm
65.35 in.
Wheelbase 2760 mm
108.66 in.
Front track 1584 mm
62.36 in.
Rear (Back) track 1588 mm
62.52 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/60 R16; 225/50 R17
Wheel rims size 16; 17
