Specifications: Opel Zafira Tourer C (facelift 2016) 1.6 DI Turbo (170 Hp) 7 Seat 2018, 2019

2017 Opel Zafira Tourer C (facelift 2016) - Photo 1

Opel Zafira Tourer C (facelift 2016) 1.6 DI Turbo (170 Hp) 7 Seat – Full specifications
General information
Brand Opel
Model Zafira
Generation Zafira Tourer C (facelift 2016)
Modification (Engine) 1.6 DI Turbo (170 Hp) 7 Seat
Start of production May, 2018 year
End of production March, 2019 year
Powertrain Architecture Internal Combustion engine
Body type MPV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 8.8-9.5 l/100 km
26.73 – 24.76 US mpg
32.1 – 29.73 UK mpg
11.36 – 10.53 km/l
Fuel consumption (economy) – extra urban 5.9-6.2 l/100 km
39.87 – 37.94 US mpg
47.88 – 45.56 UK mpg
16.95 – 16.13 km/l
Fuel consumption (economy) – combined 7.0-7.4 l/100 km
33.6 – 31.79 US mpg
40.35 – 38.17 UK mpg
14.29 – 13.51 km/l
CO2 emissions 160-170 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.9 sec
Acceleration 0 – 62 mph 9.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.4 sec
Maximum speed 210 km/h
130.49 mph
Emission standard Euro 6d
Weight-to-power ratio 9.9 kg/Hp, 100.5 Hp/tonne
Weight-to-torque ratio 6 kg/Nm, 165.6 Nm/tonne
Engine specs
Power 170 Hp @ 4750-6000 rpm.
Power per litre 106.4 Hp/l
Torque 280 Nm @ 1650-4500 rpm.
206.52 lb.-ft. @ 1650-4500 rpm.
Engine layout Front, Transverse
Engine Model/Code D16SHL
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79 mm
3.11 in.
Piston Stroke 81.5 mm
3.21 in.
Compression ratio 9.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.3 l
6.66 US qt | 5.54 UK qt

Space, Volume and weights
Kerb Weight 1691 kg
3728.02 lbs.
Max. weight 2360 kg
5202.91 lbs.
Max load 669 kg
1474.89 lbs.
Trunk (boot) space – minimum 152 l
5.37 cu. ft.
Trunk (boot) space – maximum 1792 l
63.28 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 1650 kg
3637.63 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4666 mm
183.7 in.
Width 1884 mm
74.17 in.
Width with mirrors folded 1928 mm
75.91 in.
Width including mirrors 2100 mm
82.68 in.
Height 1660 mm
65.35 in.
Wheelbase 2760 mm
108.66 in.
Front track 1584 mm
62.36 in.
Rear (Back) track 1588 mm
62.52 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/50 R17; 235/45 R18
Wheel rims size 7J x 17; 8J x 18
