Specifications: Peugeot 205 I (741AC) 1.1 (49 Hp) 1986, 1987

1983 Peugeot 205 I (741A/C) - Photo 1

Peugeot 205 I (741A/C) 1.1 (49 Hp) – Full specifications
General information
Brand Peugeot
Model 205
Generation 205 I (741A/C)
Modification (Engine) 1.1 (49 Hp)
Start of production 1986 year
End of production 1987 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 4
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.8 l/100 km
40.6 US mpg
48.7 UK mpg
17.2 km/l
Fuel consumption (economy) – extra urban 4.3 l/100 km
54.7 US mpg
65.7 UK mpg
23.3 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 17 sec
Acceleration 0 – 62 mph 17 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 16.2 sec
Maximum speed 142 km/h
88.23 mph
Weight-to-power ratio 15.1 kg/Hp, 66.2 Hp/tonne
Weight-to-torque ratio 8.7 kg/Nm, 114.9 Nm/tonne
Engine specs
Power 49 Hp @ 4800 rpm.
Power per litre 43.6 Hp/l
Torque 85 Nm @ 2800 rpm.
62.69 lb.-ft. @ 2800 rpm.
Engine layout Front, Transverse
Engine Model/Code XW7
Engine displacement 1124 cm3
68.59 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 72 mm
2.83 in.
Piston Stroke 69 mm
2.72 in.
Compression ratio 9.7:1
Number of valves per cylinder 2
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine
Valvetrain OHV
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6 l
6.34 US qt | 5.28 UK qt

Space, Volume and weights
Kerb Weight 740 kg
1631.42 lbs.
Max. weight 1195 kg
2634.52 lbs.
Max load 455 kg
1003.1 lbs.
Trunk (boot) space – minimum 216 l
7.63 cu. ft.
Trunk (boot) space – maximum 564 l
19.92 cu. ft.
Fuel tank capacity 40 l
10.57 US gal | 8.8 UK gal
Permitted trailer load with brakes (12%) 700 kg
1543.24 lbs.
Dimensions
Length 3705 mm
145.87 in.
Width 1572 mm
61.89 in.
Height 1373 mm
54.06 in.
Wheelbase 2420 mm
95.28 in.
Front track 1350 mm
53.15 in.
Rear (Back) track 1300 mm
51.18 in.
Front overhang 680 mm
26.77 in.
Rear overhang 605 mm
23.82 in.
Drag coefficient (Cd) 0.35
Minimum turning circle (turning diameter) 10.5 m
34.45 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 4 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Torsion
Front brakes Disc
Rear brakes Drum
Steering type Steering rack and pinion
Tires size 135/80 R13
Wheel rims size 13
