Specifications: Peugeot 205 I (741AC) 3-door 1.4 (60 Hp) 1983, 1984, 1985, 1986, 1987

1983 Peugeot 205 I (741A/C) 3-door - Photo 1

Peugeot 205 I (741A/C) 3-door 1.4 (60 Hp) – Full specifications
General information
Brand Peugeot
Model 205
Generation 205 I (741A/C) 3-door
Modification (Engine) 1.4 (60 Hp)
Start of production 1983 year
End of production 1987 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 4
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.9 l/100 km
34.1 US mpg
40.9 UK mpg
14.5 km/l
Fuel consumption (economy) – extra urban 4.6 l/100 km
51.1 US mpg
61.4 UK mpg
21.7 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 14.8 sec
Acceleration 0 – 62 mph 14.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 14.1 sec
Maximum speed 155 km/h
96.31 mph
Weight-to-power ratio 13.2 kg/Hp, 75.7 Hp/tonne
Weight-to-torque ratio 7.4 kg/Nm, 134.9 Nm/tonne
Engine specs
Power 60 Hp @ 5000 rpm.
Power per litre 44.1 Hp/l
Torque 107 Nm @ 2500 rpm.
78.92 lb.-ft. @ 2500 rpm.
Engine layout Front, Transverse
Engine Model/Code XY7
Engine displacement 1360 cm3
82.99 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 77 mm
3.03 in.
Compression ratio 9.3:1
Number of valves per cylinder 2
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine
Valvetrain OHV
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.8 l
6.13 US qt | 5.1 UK qt

Space, Volume and weights
Kerb Weight 793 kg
1748.27 lbs.
Max. weight 1240 kg
2733.73 lbs.
Max load 447 kg
985.47 lbs.
Trunk (boot) space – minimum 216 l
7.63 cu. ft.
Trunk (boot) space – maximum 564 l
19.92 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Permitted trailer load with brakes (12%) 800 kg
1763.7 lbs.
Dimensions
Length 3705 mm
145.87 in.
Width 1572 mm
61.89 in.
Height 1373 mm
54.06 in.
Wheelbase 2420 mm
95.28 in.
Front track 1350 mm
53.15 in.
Rear (Back) track 1300 mm
51.18 in.
Front overhang 680 mm
26.77 in.
Rear overhang 605 mm
23.82 in.
Drag coefficient (Cd) 0.35
Minimum turning circle (turning diameter) 10.5 m
34.45 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Torsion
Front brakes Disc
Rear brakes Drum
Tires size 165/70 R14
Wheel rims size 14
