Specifications: Peugeot 205 I Cabrio (741B,20D) 1.4 CJ (69 Hp) 1989, 1990, 1991, 1992, 1993, 1994

1986 Peugeot 205 I Cabrio (741B,20D) - Photo 1

Peugeot 205 I Cabrio (741B,20D) 1.4 CJ (69 Hp) – Full specifications
General information
Brand Peugeot
Model 205
Generation 205 I Cabrio (741B,20D)
Modification (Engine) 1.4 CJ (69 Hp)
Start of production 1989 year
End of production 1994 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 7.2 l/100 km
32.7 US mpg
39.2 UK mpg
13.9 km/l
Fuel consumption (economy) – extra urban 4.7 l/100 km
50 US mpg
60.1 UK mpg
21.3 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.7 sec
Acceleration 0 – 62 mph 12.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.1 sec
Maximum speed 162 km/h
100.66 mph
Weight-to-power ratio 12.8 kg/Hp, 78 Hp/tonne
Weight-to-torque ratio 8 kg/Nm, 125.4 Nm/tonne
Engine specs
Power 69 Hp @ 5600 rpm.
Power per litre 50.7 Hp/l
Torque 111 Nm @ 3400 rpm.
81.87 lb.-ft. @ 3400 rpm.
Engine layout Front, Transverse
Engine Model/Code TU3A
Engine displacement 1360 cm3
82.99 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 77 mm
3.03 in.
Compression ratio 9.3:1
Number of valves per cylinder 2
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 3.2 l
3.38 US qt | 2.82 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.8 l
6.13 US qt | 5.1 UK qt

Space, Volume and weights
Kerb Weight 885 kg
1951.09 lbs.
Max. weight 1215 kg
2678.62 lbs.
Max load 330 kg
727.53 lbs.
Trunk (boot) space – minimum 216 l
7.63 cu. ft.
Trunk (boot) space – maximum 564 l
19.92 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Permitted trailer load with brakes (12%) 900 kg
1984.16 lbs.
Dimensions
Length 3705 mm
145.87 in.
Width 1572 mm
61.89 in.
Height 1375 mm
54.13 in.
Wheelbase 2420 mm
95.28 in.
Front track 1350 mm
53.15 in.
Rear (Back) track 1304 mm
51.34 in.
Minimum turning circle (turning diameter) 10.5 m
34.45 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Torsion
Front brakes Disc
Rear brakes Drum
Steering type Steering rack and pinion
Tires size 165/70 R13
Wheel rims size 13
