Specifications: Peugeot 307 (facelift 2005) 1.6 HDi (109 Hp) 2005, 2006, 2007, 2008

2005 Peugeot 307 (facelift 2005) - Photo 1

Peugeot 307 (facelift 2005) 1.6 HDi (109 Hp) – Full specifications
General information
Brand Peugeot
Model 307
Generation 307 (facelift 2005)
Modification (Engine) 1.6 HDi (109 Hp)
Start of production 2005 year
End of production 2008 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3-5
Performance specs
Fuel consumption (economy) – urban 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
Fuel consumption (economy) – extra urban 4.3 l/100 km
54.7 US mpg
65.7 UK mpg
23.3 km/l
Fuel consumption (economy) – combined 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
CO2 emissions 129 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.2 sec
Acceleration 0 – 62 mph 11.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.6 sec
Maximum speed 188 km/h
116.82 mph
Emission standard Euro 4
Weight-to-power ratio 11.4 kg/Hp, 87.7 Hp/tonne
Weight-to-torque ratio 5.2 kg/Nm, 193.1 Nm/tonne
Engine specs
Power 109 Hp @ 4000 rpm.
Power per litre 69.9 Hp/l
Torque 240 Nm @ 1750 rpm.
177.01 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code 9HZ DV6TED4
Engine displacement 1560 cm3
95.2 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 88.3 mm
3.48 in.
Compression ratio 17.6:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt

Space, Volume and weights
Kerb Weight 1243 kg
2740.35 lbs.
Max. weight 1770 kg
3902.18 lbs.
Max load 527 kg
1161.84 lbs.
Trunk (boot) space – minimum 341 l
12.04 cu. ft.
Trunk (boot) space – maximum 1328 l
46.9 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Permitted trailer load with brakes (12%) 1360 kg
2998.29 lbs.
Permitted trailer load without brakes 655 kg
1444.03 lbs.
Dimensions
Length 4212 mm
165.83 in.
Width 1746 mm
68.74 in.
Height 1510 mm
59.45 in.
Wheelbase 2608 mm
102.68 in.
Front track 1505 mm
59.25 in.
Rear (Back) track 1500 mm
59.06 in.
Ride height (ground clearance) 120 mm
4.72 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.13 m
36.52 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 195/65 R15
Wheel rims size 15
