Specifications: Peugeot 308 SW III (Phase I, 2021) 1.5 BlueHDi (130 Hp) 2021, 2022, 2023, 2024

2022 Peugeot 308 SW III (Phase I, 2021) - Photo 1

Peugeot 308 SW III (Phase I, 2021) 1.5 BlueHDi (130 Hp) – Full specifications
General information
Brand Peugeot
Model 308
Generation 308 SW III (Phase I, 2021)
Modification (Engine) 1.5 BlueHDi (130 Hp)
Start of production September, 2021 year
End of production January, 2024 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel Type Diesel
Emission standard Euro 6.3
Weight-to-power ratio 10.6 kg/Hp, 94.1 Hp/tonne
Weight-to-torque ratio 4.6 kg/Nm, 217.1 Nm/tonne
Engine specs
Power 130 Hp @ 3750 rpm.
Power per litre 86.7 Hp/l
Torque 300 Nm @ 1750 rpm.
221.27 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code YHZ DV5RC
Engine displacement 1499 cm3
91.47 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 84.8 mm
3.34 in.
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1382 kg
3046.79 lbs.
Trunk (boot) space – minimum 608 l
21.47 cu. ft.
Trunk (boot) space – maximum 1634 l
57.7 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Dimensions
Length 4636 mm
182.52 in.
Width 1852 mm
72.91 in.
Width with mirrors folded 1860 mm
73.23 in.
Width including mirrors 2062 mm
81.18 in.
Height 1444 mm
56.85 in.
Wheelbase 2732 mm
107.56 in.
Front track 1559 mm
61.38 in.
Rear (Back) track 1553 mm
61.14 in.
Front overhang 904 mm
35.59 in.
Rear overhang 1000 mm
39.37 in.
Ride height (ground clearance) 145 mm
5.71 in.
Drag coefficient (Cd) 0.277
Minimum turning circle (turning diameter) 10.68 m
35.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16; 225/45 R17; 225/40 R18
