Specifications: Peugeot 309 (3C,3A facelift 1989) 1.4 (67 Hp) 1990, 1991, 1992, 1993

1989 Peugeot 309 (3C,3A facelift 1989) - Photo 1

Peugeot 309 (3C,3A facelift 1989) 1.4 (67 Hp) – Full specifications
General information
Brand Peugeot
Model 309
Generation 309 (3C,3A facelift 1989)
Modification (Engine) 1.4 (67 Hp)
Start of production 1990 year
End of production 1993 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3-5
Performance specs
Fuel consumption (economy) – urban 7.4 l/100 km
31.8 US mpg
38.2 UK mpg
13.5 km/l
Fuel consumption (economy) – extra urban 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
Fuel consumption (economy) – combined 6.8 l/100 km
34.6 US mpg
41.5 UK mpg
14.7 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 13.1 sec
Acceleration 0 – 62 mph 13.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.4 sec
Maximum speed 166 km/h
103.15 mph
Weight-to-power ratio 12.7 kg/Hp, 78.8 Hp/tonne
Weight-to-torque ratio 7.8 kg/Nm, 128.2 Nm/tonne
Engine specs
Power 67 Hp @ 5600 rpm.
Power per litre 49.3 Hp/l
Torque 109 Nm @ 3400 rpm.
80.39 lb.-ft. @ 3400 rpm.
Engine layout Front, Transverse
Engine Model/Code K1D TU3A
Engine displacement 1360 cm3
82.99 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 77 mm
3.03 in.
Compression ratio 9.3:1
Number of valves per cylinder 2
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine
Engine oil capacity 3.2 l
3.38 US qt | 2.82 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.7 l
6.02 US qt | 5.02 UK qt

Space, Volume and weights
Kerb Weight 850 kg
1873.93 lbs.
Max. weight 1290 kg
2843.96 lbs.
Max load 440 kg
970.03 lbs.
Trunk (boot) space – minimum 295 l
10.42 cu. ft.
Trunk (boot) space – maximum 615 l
21.72 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4050 mm
159.45 in.
Width 1630 mm
64.17 in.
Height 1380 mm
54.33 in.
Wheelbase 2470 mm
97.24 in.
Front track 1405 mm
55.31 in.
Rear (Back) track 1380 mm
54.33 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Coil spring
Rear suspension Torsion
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 165/70 SR13
