Specifications: Peugeot 405 I Break (15E) 1.9 (109 Hp) 1988, 1989, 1990, 1991, 1992

1988 Peugeot 405 I Break (15E) - Photo 1

Peugeot 405 I Break (15E) 1.9 (109 Hp) – Full specifications
General information
Brand Peugeot
Model 405
Generation 405 I Break (15E)
Modification (Engine) 1.9 (109 Hp)
Start of production 1988 year
End of production 1992 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – extra urban 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11 sec
Acceleration 0 – 62 mph 11 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 185 km/h
114.95 mph
Weight-to-power ratio 9.9 kg/Hp, 100.9 Hp/tonne
Weight-to-torque ratio 6.7 kg/Nm, 149.1 Nm/tonne
Engine specs
Power 109 Hp @ 6000 rpm.
Power per litre 57.2 Hp/l
Torque 161 Nm @ 3000 rpm.
118.75 lb.-ft. @ 3000 rpm.
Engine layout Front, Transverse
Engine Model/Code DDZ XU9M
Engine displacement 1905 cm3
116.25 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 88 mm
3.46 in.
Compression ratio 9.18:1
Number of valves per cylinder 2
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt

Space, Volume and weights
Kerb Weight 1080 kg
2380.99 lbs.
Max. weight 1580 kg
3483.3 lbs.
Max load 500 kg
1102.31 lbs.
Trunk (boot) space – minimum 814 l
28.75 cu. ft.
Trunk (boot) space – maximum 1640 l
57.92 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Permitted trailer load with brakes (12%) 1200 kg
2645.55 lbs.
Dimensions
Length 4398 mm
173.15 in.
Width 1714 mm
67.48 in.
Height 1445 mm
56.89 in.
Wheelbase 2669 mm
105.08 in.
Front track 1450 mm
57.09 in.
Rear (Back) track 1443 mm
56.81 in.
Front overhang 817 mm
32.17 in.
Rear overhang 912 mm
35.91 in.
Minimum turning circle (turning diameter) 10.55 m
34.61 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Front brakes Ventilated discs
Rear brakes Disc
Steering type Steering rack and pinion
Tires size 185/65 R14
Wheel rims size 14
