Specifications: Peugeot 408 II 1.8 CVVT (139 Hp) Automatic 2014, 2015, 2016, 2017

2014 Peugeot 408 II - Photo 1

Peugeot 408 II 1.8 CVVT (139 Hp) Automatic – Full specifications
General information
Brand Peugeot
Model 408
Generation 408 II
Modification (Engine) 1.8 CVVT (139 Hp) Automatic
Start of production 2014 year
End of production 2017 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – combined 5.9 l/100 km
39.9 US mpg
47.9 UK mpg
16.9 km/l
Fuel Type Petrol (Gasoline)
Maximum speed 200 km/h
124.27 mph
Weight-to-power ratio 9.9 kg/Hp, 101.5 Hp/tonne
Weight-to-torque ratio 8 kg/Nm, 125.5 Nm/tonne
Engine specs
Power 139 Hp
Power per litre 76.7 Hp/l
Torque 172 Nm
126.86 lb.-ft.
Engine layout Front, Transverse
Engine Model/Code EC8
Engine displacement 1813 cm3
110.64 cu. in.
Number of cylinders 4
Engine configuration Inline
Compression ratio 11:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine

Space, Volume and weights
Kerb Weight 1370 kg
3020.33 lbs.
Trunk (boot) space – minimum 455 l
16.07 cu. ft.
Fuel tank capacity 53 l
14 US gal | 11.66 UK gal
Dimensions
Length 4750 mm
187.01 in.
Width 1820 mm
71.65 in.
Height 1488 mm
58.58 in.
Wheelbase 2730 mm
107.48 in.
Front track 1555 mm
61.22 in.
Rear (Back) track 1550 mm
61.02 in.
Front overhang 940 mm
37.01 in.
Rear overhang 1080 mm
42.52 in.
Ride height (ground clearance) 124 mm
4.88 in.
Minimum turning circle (turning diameter) 10.8 m
35.43 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
