Specifications: Peugeot 5008 II (Phase II, 2020) 1.5 BlueHDi (130 Hp) 2020, 2021, 2022, 2023, 2024

2020 Peugeot 5008 II (Phase II, 2020) - Photo 1

Peugeot 5008 II (Phase II, 2020) 1.5 BlueHDi (130 Hp) – Full specifications
General information
Brand Peugeot
Model 5008
Generation 5008 II (Phase II, 2020)
Modification (Engine) 1.5 BlueHDi (130 Hp)
Start of production September, 2020 year
End of production March, 2024 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 7
Doors 5
Performance specs
Fuel consumption at Low speed (WLTP) 4.9-5.8 l/100 km
48 – 40.6 US mpg
57.6 – 48.7 UK mpg
20.4 – 17.2 km/l
Fuel consumption at Medium speed (WLTP) 4.4-5.3 l/100 km
53.5 – 44.4 US mpg
64.2 – 53.3 UK mpg
22.7 – 18.9 km/l
Fuel consumption at high speed (WLTP) 4.1-5.0 l/100 km
57.4 – 47 US mpg
68.9 – 56.5 UK mpg
24.4 – 20 km/l
Fuel consumption at very high speed (WLTP) 5.2-6.3 l/100 km
45.2 – 37.3 US mpg
54.3 – 44.8 UK mpg
19.2 – 15.9 km/l
Combined fuel consumption (WLTP) 4.6-5.6 l/100 km
51.1 – 42 US mpg
61.4 – 50.4 UK mpg
21.7 – 17.9 km/l
CO2 emissions (WLTP) 122 – 148 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.1 sec
Acceleration 0 – 62 mph 11.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 192 km/h
119.3 mph
Emission standard Euro 6
Weight-to-power ratio 11.7 kg/Hp, 85.8 Hp/tonne
Weight-to-torque ratio 5.1 kg/Nm, 198 Nm/tonne
Engine specs
Power 130 Hp @ 3750 rpm.
Power per litre 86.7 Hp/l
Torque 300 Nm @ 1750 rpm.
221.27 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code YHZ DV5RC
Engine displacement 1499 cm3
91.47 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1515 kg
3340 lbs.
Max. weight 2200 kg
4850.17 lbs.
Max load 685 kg
1510.17 lbs.
Trunk (boot) space – minimum 702 l
24.79 cu. ft.
Trunk (boot) space – maximum 2150 l
75.93 cu. ft.
Fuel tank capacity 56 l
14.79 US gal | 12.32 UK gal
AdBlue tank 17 l
4.49 US gal | 3.74 UK gal
Permitted trailer load with brakes (12%) 1300 kg
2866.01 lbs.
Permitted towbar download 70 kg
154.32 lbs.
Dimensions
Length 4641 mm
182.72 in.
Width 1844 mm
72.6 in.
Height 1646 mm
64.8 in.
Wheelbase 2840 mm
111.81 in.
Front track 1601 mm
63.03 in.
Rear (Back) track 1610 mm
63.39 in.
Front overhang 926 mm
36.46 in.
Rear overhang 875 mm
34.45 in.
Ride height (ground clearance) 236 mm
9.29 in.
Minimum turning circle (turning diameter) 11.2 m
36.75 ft.
Approach angle 19°
Departure angle 28°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Coil spring, Independent type McPherson
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/65 R17 V; 225/55 R18 V; 205/55 R19 V
Wheel rims size 17; 18; 19
