Specifications: Peugeot 508 I (Phase I, 2010) 2.0 HDI (140 Hp) FAP 2010, 2011, 2012, 2013, 2014

2010 Peugeot 508 I (Phase I, 2010) - Photo 1

Peugeot 508 I (Phase I, 2010) 2.0 HDI (140 Hp) FAP – Full specifications
General information
Brand Peugeot
Model 508
Generation 508 I (Phase I, 2010)
Modification (Engine) 2.0 HDI (140 Hp) FAP
Start of production 2010 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 6.4 l/100 km
36.8 US mpg
44.1 UK mpg
15.6 km/l
Fuel consumption (economy) – extra urban 3.9 l/100 km
60.3 US mpg
72.4 UK mpg
25.6 km/l
Fuel consumption (economy) – combined 4.8 l/100 km
49 US mpg
58.9 UK mpg
20.8 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.8 sec
Acceleration 0 – 62 mph 9.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.3 sec
Maximum speed 210 km/h
130.49 mph
Emission standard Euro 5
Weight-to-power ratio 10.2 kg/Hp, 97.9 Hp/tonne
Weight-to-torque ratio 4.5 kg/Nm, 223.8 Nm/tonne
Engine specs
Power 140 Hp @ 4000 rpm.
Power per litre 70.1 Hp/l
Torque 320-340 Nm @ 2000 rpm.
236.02 – 250.77 lb.-ft. @ 2000 rpm.
Engine layout Front, Transverse
Engine Model/Code RHF DW10BTED4
Engine displacement 1997 cm3
121.86 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 5.25 l
5.55 US qt | 4.62 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10 l
10.57 US qt | 8.8 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1430 kg
3152.61 lbs.
Max. weight 2065 kg
4552.55 lbs.
Max load 635 kg
1399.94 lbs.
Trunk (boot) space – minimum 473 l
16.7 cu. ft.
Trunk (boot) space – maximum 515 l
18.19 cu. ft.
Fuel tank capacity 72 l
19.02 US gal | 15.84 UK gal
Dimensions
Length 4792 mm
188.66 in.
Width 1920 mm
75.59 in.
Height 1456 mm
57.32 in.
Wheelbase 2817 mm
110.91 in.
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 215/55 R17; 235/45 R18
Wheel rims size 17; 18
