Specifications: Peugeot 508 I (Phase II, 2014) 1.6 e-HDi (115 Hp) FAP Automatic 2014, 2015

2014 Peugeot 508 I (Phase II, 2014) - Photo 1

Peugeot 508 I (Phase II, 2014) 1.6 e-HDi (115 Hp) FAP Automatic – Full specifications
General information
Brand Peugeot
Model 508
Generation 508 I (Phase II, 2014)
Modification (Engine) 1.6 e-HDi (115 Hp) FAP Automatic
Start of production 2014 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 4.6 l/100 km
51.1 US mpg
61.4 UK mpg
21.7 km/l
Fuel consumption (economy) – extra urban 3.7 l/100 km
63.6 US mpg
76.3 UK mpg
27 km/l
Fuel consumption (economy) – combined 4 l/100 km
58.8 US mpg
70.6 UK mpg
25 km/l
CO2 emissions 104 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.9 sec
Acceleration 0 – 62 mph 11.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.3 sec
Maximum speed 197 km/h
122.41 mph
Emission standard Euro 5
Weight-to-power ratio 12.3 kg/Hp, 81.6 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 202.1 Nm/tonne
Engine specs
Power 115 Hp @ 3600 rpm.
Power per litre 73.7 Hp/l
Torque 285 Nm @ 1750-2000 rpm.
210.21 lb.-ft. @ 1750-2000 rpm.
Engine layout Front, Transverse
Engine Model/Code 9HL DV6C
Engine displacement 1560 cm3
95.2 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 3.75 l
3.96 US qt | 3.3 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6 l
6.34 US qt | 5.28 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1410 kg
3108.52 lbs.
Max. weight 2005 kg
4420.27 lbs.
Max load 595 kg
1311.75 lbs.
Trunk (boot) space – minimum 473 l
16.7 cu. ft.
Fuel tank capacity 72 l
19.02 US gal | 15.84 UK gal
Dimensions
Length 4830 mm
190.16 in.
Width 1828 mm
71.97 in.
Height 1456 mm
57.32 in.
Wheelbase 2817 mm
110.91 in.
Front track 1579 mm
62.17 in.
Rear (Back) track 1552 mm
61.1 in.
Ride height (ground clearance) 146 mm
5.75 in.
Minimum turning circle (turning diameter) 12.2 m
40.03 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 215/60 R16; 215/55 R17
Wheel rims size 16; 17
