Specifications: Peugeot 604 2.8 GTI (150 Hp) 1983, 1984, 1985

1975 Peugeot 604 - Photo 1

Peugeot 604 2.8 GTI (150 Hp) – Full specifications
General information
Brand Peugeot
Model 604
Generation 604
Modification (Engine) 2.8 GTI (150 Hp)
Start of production 1983 year
End of production 1985 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 15.7 l/100 km
15 US mpg
18 UK mpg
6.4 km/l
Fuel consumption (economy) – extra urban 9.2 l/100 km
25.6 US mpg
30.7 UK mpg
10.9 km/l
Fuel consumption (economy) – combined 11.7 l/100 km
20.1 US mpg
24.1 UK mpg
8.5 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.8 sec
Acceleration 0 – 62 mph 11.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.2 sec
Maximum speed 185 km/h
114.95 mph
Weight-to-power ratio 9.7 kg/Hp, 103.4 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 162.1 Nm/tonne
Engine specs
Power 150 Hp @ 5650 rpm.
Power per litre 52.7 Hp/l
Torque 235 Nm @ 3000 rpm.
173.33 lb.-ft. @ 3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code ZNJ 154A
Engine displacement 2849 cm3
173.86 cu. in.
Number of cylinders 6
Engine configuration V-engine
Compression ratio 9:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine

Space, Volume and weights
Kerb Weight 1450 kg
3196.7 lbs.
Max. weight 1960 kg
4321.06 lbs.
Max load 510 kg
1124.36 lbs.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4720 mm
185.83 in.
Width 1780 mm
70.08 in.
Wheelbase 2800 mm
110.24 in.
Front track 1500 mm
59.06 in.
Rear (Back) track 1440 mm
56.69 in.
Minimum turning circle (turning diameter) 11.50 m
37.73 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Power steering Hydraulic Steering
Tires size 205/60 R15 H
Wheel rims size 6J X 15 FHH15
