Specifications: Peugeot Rifter L2 1.5 BlueHDi (102 Hp) 2020, 2021, 2022, 2023, 2024

2020 Peugeot Rifter L2 - Photo 1

Peugeot Rifter L2 1.5 BlueHDi (102 Hp) – Full specifications
General information
Brand Peugeot
Model Rifter
Generation Rifter L2
Modification (Engine) 1.5 BlueHDi (102 Hp)
Start of production April, 2020 year
End of production March, 2024 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 7
Doors 5
Performance specs
Fuel consumption at Low speed (WLTP) 5.1-5.9 l/100 km
46.1 – 39.9 US mpg
55.4 – 47.9 UK mpg
19.6 – 16.9 km/l
Fuel consumption at Medium speed (WLTP) 4.5-5.5 l/100 km
52.3 – 42.8 US mpg
62.8 – 51.4 UK mpg
22.2 – 18.2 km/l
Fuel consumption at high speed (WLTP) 4.2-5.1 l/100 km
56 – 46.1 US mpg
67.3 – 55.4 UK mpg
23.8 – 19.6 km/l
Fuel consumption at very high speed (WLTP) 5.7-6.8 l/100 km
41.3 – 34.6 US mpg
49.6 – 41.5 UK mpg
17.5 – 14.7 km/l
Combined fuel consumption (WLTP) 4.9-5.9 l/100 km
48 – 39.9 US mpg
57.6 – 47.9 UK mpg
20.4 – 16.9 km/l
CO2 emissions (WLTP) 141-154 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 15 sec
Acceleration 0 – 62 mph 15 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 14.3 sec
Maximum speed 172 km/h
106.88 mph
Emission standard Euro 6d-ISC
Weight-to-power ratio 15.1 kg/Hp, 66.2 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 162.3 Nm/tonne
Engine specs
Power 102 Hp @ 3750 rpm.
Power per litre 68 Hp/l
Torque 250 Nm @ 1750 rpm.
184.39 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code YHY DV5RD
Engine displacement 1499 cm3
91.47 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1540 kg
3395.12 lbs.
Max. weight 2320 kg
5114.72 lbs.
Max load 780 kg
1719.61 lbs.
Trunk (boot) space – minimum 1050 l
37.08 cu. ft.
Trunk (boot) space – maximum 3500 l
123.6 cu. ft.
Fuel tank capacity 51 l
13.47 US gal | 11.22 UK gal
AdBlue tank 17 l
4.49 US gal | 3.74 UK gal
Permitted trailer load with brakes (12%) 1050 kg
2314.85 lbs.
Permitted towbar download 74 kg
163.14 lbs.
Dimensions
Length 4753 mm
187.13 in.
Width 1848 mm
72.76 in.
Width with mirrors folded 1921 mm
75.63 in.
Width including mirrors 2107 mm
82.95 in.
Height 1879-1882 mm
73.98 – 74.09 in.
Wheelbase 2975 mm
117.13 in.
Front track 1553 mm
61.14 in.
Rear (Back) track 1567 mm
61.69 in.
Front overhang 892 mm
35.12 in.
Rear overhang 886 mm
34.88 in.
Ride height (ground clearance) 216 mm
8.5 in.
Approach angle 17.5°
Departure angle 25.7°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Wishbone
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 215/65 R16 95U; 215/60 R17 95U
Wheel rims size 6.5J x 16 ET47; 7.0J x 17 ET44
