Specifications: Peugeot Traveller L2 e-Traveller 75 kWh (136 Hp) 2020, 2021, 2022, 2023, 2024

2016 Peugeot Traveller L2 - Photo 1

Peugeot Traveller L2 e-Traveller 75 kWh (136 Hp) – Full specifications
General information
Brand Peugeot
Model Traveller
Generation Traveller L2
Modification (Engine) e-Traveller 75 kWh (136 Hp)
Start of production October, 2020 year
End of production April, 2024 year
Powertrain Architecture BEV (Electric Vehicle)
Body type Minivan
Seats 5-8
Doors 5
Performance specs
Fuel Type Electricity
Acceleration 0 – 100 km/h 14.3 sec
Acceleration 0 – 62 mph 14.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 13.6 sec
Maximum speed 130 km/h
80.78 mph
Weight-to-power ratio 15.2 kg/Hp, 65.9 Hp/tonne
Weight-to-torque ratio 7.9 kg/Nm, 125.9 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 75 kWh
Battery technology Lithium-ion (Li-Ion)
Battery location Below the floor
All-electric range (WLTP) 322 km
200.08 mi
Average Energy consumption (WLTP) 27.8 kWh/100 km

44.74 kWh/100 mi
75 MPGe
3.6 km/kWh
2.2 mi/kWh
Charging ports Log in to see.Log in to see.
Electric motor 1
Electric motor power 136 Hp @ 5500 rpm.
Electric motor Torque 260 Nm

191.77 lb.-ft.
Electric motor model/code ZK01
Electric motor location Front axle, Transverse
Electric motor type Synchronous
System power 136 Hp @ 5500 rpm.
System torque 260 Nm
191.77 lb.-ft.

Space, Volume and weights
Kerb Weight 2065-2412 kg
4552.55 – 5317.55 lbs.
Max. weight 3100 kg
6834.33 lbs.
Max load 688-1035 kg
1516.78 – 2281.78 lbs.
Trunk (boot) space – minimum 603-798 l
21.29 – 28.18 cu. ft.
Trunk (boot) space – maximum 2700 l
95.35 cu. ft.
Dimensions
Length 4959 mm
195.24 in.
Width 1920 mm
75.59 in.
Width including mirrors 2204 mm
86.77 in.
Height 1877 mm
73.9 in.
Wheelbase 3275 mm
128.94 in.
Front track 1630 mm
64.17 in.
Rear (Back) track 1618 mm
63.7 in.
Front overhang 881 mm
34.69 in.
Rear overhang 803 mm
31.61 in.
Minimum turning circle (turning diameter) 12.9 m
42.32 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture One electric motor drives the front wheels.
Drive wheel Front wheel drive
Number of gears and type of gearbox 1 gears, automatic transmission
Front suspension Independent type McPherson
Rear suspension Independent coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17 101V
Wheel rims size 17
