Specifications: Porsche 911 (991 II) Carrera S 3.0 (420 Hp) 2015, 2016, 2017, 2018

2017 Porsche 911 (991 II) - Photo 1

Porsche 911 (991 II) Carrera S 3.0 (420 Hp) – Full specifications
General information
Brand Porsche
Model 911
Generation 911 (991 II)
Modification (Engine) Carrera S 3.0 (420 Hp)
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 12.2 l/100 km
19.3 US mpg
23.2 UK mpg
8.2 km/l
Fuel consumption (economy) – extra urban 6.6 l/100 km
35.6 US mpg
42.8 UK mpg
15.2 km/l
Fuel consumption (economy) – combined 8.7 l/100 km
27 US mpg
32.5 UK mpg
11.5 km/l
CO2 emissions 199 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 4.3 sec
Acceleration 0 – 62 mph 4.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 4.1 sec
Maximum speed 308 km/h
191.38 mph
Emission standard Euro 6
Weight-to-power ratio 3.4 kg/Hp, 291.7 Hp/tonne
Weight-to-torque ratio 2.9 kg/Nm, 347.2 Nm/tonne
Engine specs
Power 420 Hp @ 6500 rpm.
Power per litre 140.9 Hp/l
Torque 500 Nm @ 1700-5000 rpm.
368.78 lb.-ft. @ 1700-5000 rpm.
Engine layout Rear, Longitudinal
Engine Model/Code MA2.01, MA2.02
Engine displacement 2981 cm3
181.91 cu. in.
Number of cylinders 6
Engine configuration Boxer
Cylinder Bore 91 mm
3.58 in.
Piston Stroke 76.4 mm
3.01 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration BiTurbo, Intercooler
Engine oil capacity 8 l
8.45 US qt | 7.04 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 28.3 l
29.9 US qt | 24.9 UK qt

Space, Volume and weights
Kerb Weight 1440 kg
3174.66 lbs.
Max. weight 1900 kg
4188.78 lbs.
Max load 460 kg
1014.13 lbs.
Trunk (boot) space – minimum 145 l
5.12 cu. ft.
Trunk (boot) space – maximum 260 l
9.18 cu. ft.
Fuel tank capacity 64 l
16.91 US gal | 14.08 UK gal
Dimensions
Length 4499 mm
177.13 in.
Width 1808 mm
71.18 in.
Width including mirrors 1978 mm
77.87 in.
Height 1302 mm
51.26 in.
Wheelbase 2450 mm
96.46 in.
Front track 1543 mm
60.75 in.
Rear (Back) track 1518 mm
59.76 in.
Drag coefficient (Cd) 0.30
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 7 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 245/35 ZR 20; 305/30 ZR 20
Wheel rims size 8.5J x 20; 11.5J x 20
