Specifications: Porsche 911 (996, facelift 2001) Carrera 4 3.6 (320 Hp) 2001, 2002, 2003, 2004

2002 Porsche 911 (996, facelift 2001) - Photo 1

Porsche 911 (996, facelift 2001) Carrera 4 3.6 (320 Hp) – Full specifications
General information
Brand Porsche
Model 911
Generation 911 (996, facelift 2001)
Modification (Engine) Carrera 4 3.6 (320 Hp)
Start of production 2001 year
End of production 2004 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 16.3 l/100 km
14.4 US mpg
17.3 UK mpg
6.1 km/l
Fuel consumption (economy) – extra urban 8.3 l/100 km
28.3 US mpg
34 UK mpg
12 km/l
Fuel consumption (economy) – combined 11.3 l/100 km
20.8 US mpg
25 UK mpg
8.8 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 5 sec
Acceleration 0 – 62 mph 5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 4.8 sec
Maximum speed 285 km/h
177.09 mph
Weight-to-power ratio 4.5 kg/Hp, 223.8 Hp/tonne
Weight-to-torque ratio 3.9 kg/Nm, 258.7 Nm/tonne
Engine specs
Power 320 Hp @ 6800 rpm.
Power per litre 89 Hp/l
Torque 370 Nm @ 4250 rpm.
272.9 lb.-ft. @ 4250 rpm.
Engine layout Rear, Longitudinal
Engine Model/Code M96.05
Engine displacement 3596 cm3
219.44 cu. in.
Number of cylinders 6
Engine configuration Boxer
Cylinder Bore 96 mm
3.78 in.
Piston Stroke 82.8 mm
3.26 in.
Compression ratio 11.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 8.8 l
9.3 US qt | 7.74 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 31 l
32.76 US qt | 27.28 UK qt

Space, Volume and weights
Kerb Weight 1430 kg
3152.61 lbs.
Max. weight 1850 kg
4078.55 lbs.
Max load 420 kg
925.94 lbs.
Trunk (boot) space – maximum 100 l
3.53 cu. ft.
Fuel tank capacity 64 l
16.91 US gal | 14.08 UK gal
Dimensions
Length 4430 mm
174.41 in.
Width 1770 mm
69.69 in.
Height 1305 mm
51.38 in.
Wheelbase 2350 mm
92.52 in.
Front track 1465 mm
57.68 in.
Rear (Back) track 1500 mm
59.06 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/50 R17; 255/40 R17
Wheel rims size 7J x 17; 9J x 17
