Specifications: Porsche 911 (997) Carrera 4 3.6 (325 Hp) Tiptronic S 2005, 2006, 2007, 2008

2005 Porsche 911 (997) - Photo 1

Porsche 911 (997) Carrera 4 3.6 (325 Hp) Tiptronic S – Full specifications
General information
Brand Porsche
Model 911
Generation 911 (997)
Modification (Engine) Carrera 4 3.6 (325 Hp) Tiptronic S
Start of production 2005 year
End of production 2008 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 17.4 l/100 km
13.5 US mpg
16.2 UK mpg
5.7 km/l
Fuel consumption (economy) – extra urban 8.6 l/100 km
27.4 US mpg
32.8 UK mpg
11.6 km/l
Fuel consumption (economy) – combined 11.6 l/100 km
20.3 US mpg
24.4 UK mpg
8.6 km/l
CO2 emissions 280 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 5.6 sec
Acceleration 0 – 62 mph 5.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 5.3 sec
Maximum speed 275 km/h
170.88 mph
Emission standard Euro 4
Weight-to-power ratio 4.6 kg/Hp, 218.1 Hp/tonne
Weight-to-torque ratio 4 kg/Nm, 248.3 Nm/tonne
Engine specs
Power 325 Hp @ 6800 rpm.
Power per litre 90.4 Hp/l
Torque 370 Nm @ 4250 rpm.
272.9 lb.-ft. @ 4250 rpm.
Engine layout Rear, Longitudinal
Engine Model/Code M96.05
Engine displacement 3596 cm3
219.44 cu. in.
Number of cylinders 6
Engine configuration Boxer
Cylinder Bore 96 mm
3.78 in.
Piston Stroke 82.8 mm
3.26 in.
Compression ratio 11.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 8.3 l
8.77 US qt | 7.3 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 31 l
32.76 US qt | 27.28 UK qt

Space, Volume and weights
Kerb Weight 1490 kg
3284.89 lbs.
Max. weight 1910 kg
4210.83 lbs.
Max load 420 kg
925.94 lbs.
Trunk (boot) space – maximum 105 l
3.71 cu. ft.
Fuel tank capacity 67 l
17.7 US gal | 14.74 UK gal
Dimensions
Length 4427 mm
174.29 in.
Width 1852 mm
72.91 in.
Height 1310 mm
51.57 in.
Wheelbase 2350 mm
92.52 in.
Front track 1465 mm
57.68 in.
Rear (Back) track 1500 mm
59.06 in.
Drag coefficient (Cd) 0.30
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, automatic transmission Tiptronic S
Front suspension Independent type McPherson
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 235/40 R18ZR; 265/40 R18ZR
Wheel rims size 8J x 18; 11J x 18
