Specifications: Proton e.MAS 7 60.22 kWh (218 Hp) Electric 2024, 2025

2025 Proton e.MAS 7 - Photo 1

Proton e.MAS 7 60.22 kWh (218 Hp) Electric – Full specifications
General information
Brand Proton
Model e.MAS 7
Generation e.MAS 7
Modification (Engine) 60.22 kWh (218 Hp) Electric
Start of production December, 2024 year
Powertrain Architecture BEV (Electric Vehicle)
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel Type Electricity
Acceleration 0 – 100 km/h 7.1 sec
Acceleration 0 – 62 mph 7.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.7 sec
Maximum speed 175 km/h
108.74 mph
Weight-to-power ratio 8.1 kg/Hp, 123.5 Hp/tonne
Weight-to-torque ratio 5.5 kg/Nm, 181.3 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 60.22 kWh
Battery voltage 376 V
Battery technology Lithium iron phosphate (LiFePO4)
Battery location Below the floor
All-electric range (WLTP) 410 km
254.76 mi
All-electric range (NEDC) 470 km
292.04 mi
Charging ports Log in to see.Log in to see.
Electric motor 1
Electric motor power 218 Hp
Electric motor Torque 320 Nm

236.02 lb.-ft.
Electric motor model/code TZ184XY101
Maximum revolutions of the electric motor 16500 rpm.
Electric motor location Front axle, Transverse
Electric motor type Synchronous
System power 218 Hp
System torque 320 Nm
236.02 lb.-ft.

Space, Volume and weights
Kerb Weight 1765 kg
3891.16 lbs.
Max. weight 2215 kg
4883.24 lbs.
Max load 450 kg
992.08 lbs.
Trunk (boot) space – minimum 461 l
16.28 cu. ft.
Trunk (boot) space – maximum 1877 l
66.29 cu. ft.
Dimensions
Length 4615 mm
181.69 in.
Width 1901 mm
74.84 in.
Height 1670 mm
65.75 in.
Wheelbase 2750 mm
108.27 in.
Front track 1620 mm
63.78 in.
Rear (Back) track 1611 mm
63.43 in.
Ride height (ground clearance) 173 mm
6.81 in.
Drag coefficient (Cd) 0.275
Drivetrain, brakes and suspension specs
Drivetrain Architecture One electric motor drives the front wheels.
Drive wheel Front wheel drive
Number of gears and type of gearbox 1 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/50 R19
Wheel rims size 19
