Specifications: Tatra T700 3.5 i V8 16V (168 Hp) 1996, 1997, 1998, 1999

1996 Tatra T700 - Photo 1

Tatra T700 3.5 i V8 16V (168 Hp) – Full specifications
General information
Brand Tatra
Model T700
Generation T700
Modification (Engine) 3.5 i V8 16V (168 Hp)
Start of production 1996 year
End of production 1999 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 4
Doors 4
Performance specs
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.4 sec
Acceleration 0 – 62 mph 11.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.8 sec
Maximum speed 190 km/h
118.06 mph
Weight-to-power ratio 10.8 kg/Hp, 92.8 Hp/tonne
Weight-to-torque ratio 6.7 kg/Nm, 149.2 Nm/tonne
Engine specs
Power 168 Hp @ 5200 rpm.
Power per litre 48.1 Hp/l
Torque 270 Nm @ 3300 rpm.
199.14 lb.-ft. @ 3300 rpm.
Engine layout Rear, Longitudinal
Engine displacement 3495 cm3
213.28 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 85 mm
3.35 in.
Piston Stroke 77 mm
3.03 in.
Compression ratio 9.3:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC

Space, Volume and weights
Kerb Weight 1810 kg
3990.37 lbs.
Max. weight 2260 kg
4982.45 lbs.
Max load 450 kg
992.08 lbs.
Trunk (boot) space – minimum 430 l
15.19 cu. ft.
Fuel tank capacity 72 l
19.02 US gal | 15.84 UK gal
Dimensions
Length 5135 mm
202.17 in.
Width 1800 mm
70.87 in.
Height 1500 mm
59.06 in.
Wheelbase 3130 mm
123.23 in.
Front track 1530 mm
60.24 in.
Rear (Back) track 1530 mm
60.24 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Spring-loaded rack
Rear suspension Inclined Lever
Front brakes Ventilated discs
Rear brakes Ventilated discs
Power steering Hydraulic Steering
Tires size 205/65 R15
