Specifications: Toyota 4Runner III 3.0 TD (125 Hp) Automatic 1995, 1996, 1997, 1998, 1999

1996 Toyota 4Runner III - Photo 1

Toyota 4Runner III 3.0 TD (125 Hp) Automatic – Full specifications
General information
Brand Toyota
Model 4Runner
Generation 4Runner III
Modification (Engine) 3.0 TD (125 Hp) Automatic
Start of production 1995 year
End of production 1999 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 15 l/100 km
15.68 US mpg
18.83 UK mpg
6.67 km/l
Fuel consumption (economy) – extra urban 5.6 l/100 km
42 US mpg
50.44 UK mpg
17.86 km/l
Fuel consumption (economy) – combined 10 l/100 km
23.52 US mpg
28.25 UK mpg
10 km/l
Fuel Type Diesel
Maximum speed 150 km/h
93.21 mph
Weight-to-power ratio 13.8 kg/Hp, 72.3 Hp/tonne
Weight-to-torque ratio 5.9 kg/Nm, 170.5 Nm/tonne
Engine specs
Power 125 Hp @ 3600 rpm.
Power per litre 41.9 Hp/l
Torque 295 Nm @ 2000 rpm.
217.58 lb.-ft. @ 2000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 1KZ-TE
Engine displacement 2982 cm3
181.97 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 96 mm
3.78 in.
Piston Stroke 103 mm
4.06 in.
Compression ratio 21.2:1
Number of valves per cylinder 2
Fuel injection system Precombustion chamber injection
Engine aspiration Turbocharger
Valvetrain OHC
Engine oil capacity 7 l
7.4 US qt | 6.16 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10 l
10.57 US qt | 8.8 UK qt

Space, Volume and weights
Kerb Weight 1730 kg
3814 lbs.
Max. weight 2430 kg
5357.23 lbs.
Max load 700 kg
1543.24 lbs.
Trunk (boot) space – minimum 1263 l
44.6 cu. ft.
Trunk (boot) space – maximum 2257 l
79.71 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4539 mm
178.7 in.
Width 1689 mm
66.5 in.
Height 1689-1745 mm
66.5 – 68.7 in.
Wheelbase 2675 mm
105.31 in.
Front track 1506 mm
59.29 in.
Rear (Back) track 1496-1509 mm
58.9 – 59.41 in.
Ride height (ground clearance) 216-241 mm
8.5 – 9.49 in.
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Approach angle 32-36°
Departure angle 26-29°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 225/75 R15; 265/70 R16
Wheel rims size 7J x 15; 7J x 16
