Specifications: Toyota Alphard III (facelift 2018) 2.5 (152 Hp) Hybrid E-Four e-CVT 2018, 2019, 2020, 2021, 2022, 2023

2018 Toyota Alphard III (facelift 2018) - Photo 1

Toyota Alphard III (facelift 2018) 2.5 (152 Hp) Hybrid E-Four e-CVT – Full specifications
General information
Brand Toyota
Model Alphard
Generation Alphard III (facelift 2018)
Modification (Engine) 2.5 (152 Hp) Hybrid E-Four e-CVT
Start of production January, 2018 year
End of production June, 2023 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body type Minivan
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – combined 5.4 l/100 km
43.56 US mpg
52.31 UK mpg
18.52 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 13.9 kg/Hp, 72 Hp/tonne
Weight-to-torque ratio 10.2 kg/Nm, 97.6 Nm/tonne
Electric cars and hybrids specs
Battery technology Nickel-metal hydride (NiMH)
Electric motor 1
Electric motor power 143 Hp
Electric motor Torque 270 Nm

199.14 lb.-ft.
Electric motor model/code 2JM
Electric motor type Synchronous
Electric motor 2
Electric motor power 68 Hp
Electric motor Torque 139 Nm

102.52 lb.-ft.
Electric motor model/code 2FM
Electric motor type Synchronous
Internal combustion engine specs
Power 152 Hp @ 5700 rpm.
Power per litre 61 Hp/l
Torque 206 Nm @ 4400-4800 rpm.
151.94 lb.-ft. @ 4400-4800 rpm.
Engine layout Front, Transverse
Engine Model/Code 2AR-FXE
Engine displacement 2493 cm3
152.13 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 90 mm
3.54 in.
Piston Stroke 98 mm
3.86 in.
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 4.4 l
4.65 US qt | 3.87 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.3 l
9.83 US qt | 8.18 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 2110 kg
4651.75 lbs.
Max. weight 2495 kg
5500.53 lbs.
Max load 385 kg
848.78 lbs.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Dimensions
Length 4945 mm
194.69 in.
Width 1850 mm
72.83 in.
Height 1950 mm
76.77 in.
Wheelbase 3000 mm
118.11 in.
Front track 1600 mm
62.99 in.
Rear (Back) track 1595 mm
62.8 in.
Ride height (ground clearance) 165 mm
6.5 in.
Minimum turning circle (turning diameter) 11.2 m
36.75 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox automatic transmission e-CVT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/65 R16; 225/60 R17
Wheel rims size 6.5J x 16; 6.5J x 17
