Specifications: Toyota Auris I 1.6 i 16V VVT-i (124 Hp) MMT 2006, 2007, 2008, 2009, 2010

2007 Toyota Auris I - Photo 1

Toyota Auris I 1.6 i 16V VVT-i (124 Hp) MMT – Full specifications
General information
Brand Toyota
Model Auris
Generation Auris I
Modification (Engine) 1.6 i 16V VVT-i (124 Hp) MMT
Start of production 2006 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 8.5 l/100 km
27.67 US mpg
33.23 UK mpg
11.76 km/l
Fuel consumption (economy) – extra urban 5.9 l/100 km
39.87 US mpg
47.88 UK mpg
16.95 km/l
Fuel consumption (economy) – combined 6.9 l/100 km
34.09 US mpg
40.94 UK mpg
14.49 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.1 sec
Acceleration 0 – 62 mph 12.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.5 sec
Maximum speed 190 km/h
118.06 mph
Emission standard Euro 4
Weight-to-power ratio 9.9 kg/Hp, 100.8 Hp/tonne
Weight-to-torque ratio 7.8 kg/Nm, 127.6 Nm/tonne
Engine specs
Power 124 Hp @ 6000 rpm.
Power per litre 77.6 Hp/l
Torque 157 Nm @ 5200 rpm.
115.8 lb.-ft. @ 5200 rpm.
Engine layout Front, Transverse
Engine Model/Code 1ZR-FE
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80.5 mm
3.17 in.
Piston Stroke 78.5 mm
3.09 in.
Compression ratio 10.2:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.5 l
5.81 US qt | 4.84 UK qt

Space, Volume and weights
Kerb Weight 1230 kg
2711.69 lbs.
Max. weight 1750 kg
3858.09 lbs.
Max load 520 kg
1146.4 lbs.
Trunk (boot) space – minimum 354 l
12.5 cu. ft.
Trunk (boot) space – maximum 761 l
26.87 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4220 mm
166.14 in.
Width 1760 mm
69.29 in.
Height 1515 mm
59.65 in.
Wheelbase 2600 mm
102.36 in.
Front track 1524 mm
60 in.
Rear (Back) track 1522 mm
59.92 in.
Minimum turning circle (turning diameter) 10.2 m
33.46 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Spring Strut
Rear suspension Torsion
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16
