Specifications: Toyota Avanza I (facelift 2006) 1.3 (94 Hp) 2006, 2007, 2008, 2009, 2010, 2011

2006 Toyota Avanza I (facelift 2006) - Photo 1

Toyota Avanza I (facelift 2006) 1.3 (94 Hp) – Full specifications
General information
Brand Toyota
Model Avanza
Generation Avanza I (facelift 2006)
Modification (Engine) 1.3 (94 Hp)
Start of production 2006 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type MPV
Seats 7
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 11.1 kg/Hp, 90 Hp/tonne
Weight-to-torque ratio 8.7 kg/Nm, 114.8 Nm/tonne
Engine specs
Power 94 Hp @ 6000 rpm.
Power per litre 72.4 Hp/l
Torque 120 Nm @ 4400 rpm.
88.51 lb.-ft. @ 4400 rpm.
Engine layout Front, Longitudinal
Engine Model/Code K3-VE
Engine displacement 1298 cm3
79.21 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 72 mm
2.83 in.
Piston Stroke 79.7 mm
3.14 in.
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.2 l
3.38 US qt | 2.82 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1045 kg
2303.83 lbs.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Dimensions
Length 4120 mm
162.2 in.
Width 1630 mm
64.17 in.
Height 1695 mm
66.73 in.
Wheelbase 2655 mm
104.53 in.
Front track 1405 mm
55.31 in.
Rear (Back) track 1415 mm
55.71 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Tires size 185/70 R14
Wheel rims size 14
