Specifications: Toyota Avensis III Wagon (facelift 2012) 2.0 D-4D (124 Hp) 2012, 2013, 2014, 2015

2012 Toyota Avensis III Wagon (facelift 2012) - Photo 1

Toyota Avensis III Wagon (facelift 2012) 2.0 D-4D (124 Hp) – Full specifications
General information
Brand Toyota
Model Avensis
Generation Avensis III Wagon (facelift 2012)
Modification (Engine) 2.0 D-4D (124 Hp)
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.6 l/100 km
42 US mpg
50.44 UK mpg
17.86 km/l
Fuel consumption (economy) – extra urban 3.9 l/100 km
60.31 US mpg
72.43 UK mpg
25.64 km/l
Fuel consumption (economy) – combined 4.5 l/100 km
52.27 US mpg
62.77 UK mpg
22.22 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 10 sec
Acceleration 0 – 62 mph 10 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.5 sec
Maximum speed 200 km/h
124.27 mph
Emission standard Euro 5 B
Weight-to-power ratio 12.2 kg/Hp, 82.1 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 205.3 Nm/tonne
Engine specs
Power 124 Hp @ 3600 rpm.
Power per litre 62.1 Hp/l
Torque 310 Nm @ 2400 rpm.
228.64 lb.-ft. @ 2400 rpm.
Engine layout Front, Transverse
Engine Model/Code 1AD-FTV
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 86 mm
3.39 in.
Compression ratio 15.8:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 6.3 l
6.66 US qt | 5.54 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.4 l
7.82 US qt | 6.51 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1510 kg
3328.98 lbs.
Max. weight 2130 kg
4695.85 lbs.
Max load 620 kg
1366.87 lbs.
Trunk (boot) space – minimum 543 l
19.18 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4780 mm
188.19 in.
Width 1810 mm
71.26 in.
Height 1480 mm
58.27 in.
Wheelbase 2700 mm
106.3 in.
Front track 1550 mm
61.02 in.
Rear (Back) track 1540 mm
60.63 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
