Specifications: Toyota Avensis III Wagon (facelift 2012) 2.2 D-CAT (150 Hp) Automatic 2012, 2013, 2014, 2015

2012 Toyota Avensis III Wagon (facelift 2012) - Photo 1

Toyota Avensis III Wagon (facelift 2012) 2.2 D-CAT (150 Hp) Automatic – Full specifications
General information
Brand Toyota
Model Avensis
Generation Avensis III Wagon (facelift 2012)
Modification (Engine) 2.2 D-CAT (150 Hp) Automatic
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.9 l/100 km
29.77 US mpg
35.76 UK mpg
12.66 km/l
Fuel consumption (economy) – extra urban 5.3 l/100 km
44.38 US mpg
53.3 UK mpg
18.87 km/l
Fuel consumption (economy) – combined 6.2 l/100 km
37.94 US mpg
45.56 UK mpg
16.13 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.8 sec
Acceleration 0 – 62 mph 9.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.3 sec
Maximum speed 205 km/h
127.38 mph
Emission standard Euro 5 B
Weight-to-power ratio 10.4 kg/Hp, 96.2 Hp/tonne
Weight-to-torque ratio 4.6 kg/Nm, 217.9 Nm/tonne
Engine specs
Power 150 Hp @ 3600 rpm.
Power per litre 67.2 Hp/l
Torque 340 Nm @ 2800 rpm.
250.77 lb.-ft. @ 2800 rpm.
Engine layout Front, Transverse
Engine Model/Code 2AD-FHV
Engine displacement 2231 cm3
136.14 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 96 mm
3.78 in.
Compression ratio 15.7:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.9 l
6.23 US qt | 5.19 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.4 l
7.82 US qt | 6.51 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1560 kg
3439.21 lbs.
Max. weight 2140 kg
4717.89 lbs.
Max load 580 kg
1278.68 lbs.
Trunk (boot) space – minimum 543 l
19.18 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4780 mm
188.19 in.
Width 1810 mm
71.26 in.
Height 1480 mm
58.27 in.
Wheelbase 2700 mm
106.3 in.
Front track 1550 mm
61.02 in.
Rear (Back) track 1540 mm
60.63 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
