Specifications: Toyota Avensis III Wagon (facelift 2015) 1.6 Valvematic (132 Hp) 2015, 2016, 2017, 2018

2015 Toyota Avensis III Wagon (facelift 2015) - Photo 1

Toyota Avensis III Wagon (facelift 2015) 1.6 Valvematic (132 Hp) – Full specifications
General information
Brand Toyota
Model Avensis
Generation Avensis III Wagon (facelift 2015)
Modification (Engine) 1.6 Valvematic (132 Hp)
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 8 l/100 km
29.4 US mpg
35.31 UK mpg
12.5 km/l
Fuel consumption (economy) – extra urban 5.1 l/100 km
46.12 US mpg
55.39 UK mpg
19.61 km/l
Fuel consumption (economy) – combined 6.2 l/100 km
37.94 US mpg
45.56 UK mpg
16.13 km/l
CO2 emissions 143 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.6 sec
Acceleration 0 – 62 mph 10.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.1 sec
Maximum speed 195 km/h
121.17 mph
Emission standard Euro 6 W
Engine specs
Power 132 Hp @ 6400 rpm.
Power per litre 82.6 Hp/l
Torque 160 Nm @ 4400 rpm.
118.01 lb.-ft. @ 4400 rpm.
Engine layout Front, Transverse
Engine Model/Code 1ZR-FAE
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Compression ratio 10.7:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.3 l
6.66 US qt | 5.54 UK qt

Space, Volume and weights
Max. weight 1970 kg
4343.11 lbs.
Trunk (boot) space – minimum 543 l
19.18 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Max. roof load 103 kg
227.08 lbs.
Permitted trailer load with brakes (12%) 1400 kg
3086.47 lbs.
Permitted trailer load without brakes 500 kg
1102.31 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4820 mm
189.76 in.
Width 1810 mm
71.26 in.
Height 1480 mm
58.27 in.
Wheelbase 2700 mm
106.3 in.
Front track 1550 mm
61.02 in.
Rear (Back) track 1540 mm
60.63 in.
Drag coefficient (Cd) 0.29
Minimum turning circle (turning diameter) 10.8 m
35.43 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/60 R16
Wheel rims size 6.5J x 16
