Specifications: Toyota Avensis Wagon (T22) 1.6 (110 Hp) 1997, 1998, 1999, 2000, 2001, 2002, 2003

1997 Toyota Avensis Wagon (T22) - Photo 1

Toyota Avensis Wagon (T22) 1.6 (110 Hp) – Full specifications
General information
Brand Toyota
Model Avensis
Generation Avensis Wagon (T22)
Modification (Engine) 1.6 (110 Hp)
Start of production 1997 year
End of production 2003 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 11 l/100 km
21.38 US mpg
25.68 UK mpg
9.09 km/l
Fuel consumption (economy) – extra urban 6.5 l/100 km
36.19 US mpg
43.46 UK mpg
15.38 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.9 sec
Acceleration 0 – 62 mph 11.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.3 sec
Maximum speed 190 km/h
118.06 mph
Weight-to-power ratio 11.6 kg/Hp, 85.9 Hp/tonne
Weight-to-torque ratio 8.8 kg/Nm, 113.3 Nm/tonne
Engine specs
Power 110 Hp @ 6000 rpm.
Power per litre 69.3 Hp/l
Torque 145 Nm @ 4800 rpm.
106.95 lb.-ft. @ 4800 rpm.
Engine layout Front, Transverse
Engine Model/Code 3ZZ-FE
Engine displacement 1587 cm3
96.84 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 77 mm
3.03 in.
Compression ratio 9.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.7 l
3.91 US qt | 3.26 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.4 l
7.82 US qt | 6.51 UK qt

Space, Volume and weights
Kerb Weight 1280 kg
2821.92 lbs.
Max. weight 1775 kg
3913.21 lbs.
Max load 495 kg
1091.29 lbs.
Trunk (boot) space – minimum 580 l
20.48 cu. ft.
Trunk (boot) space – maximum 1996 l
70.49 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4570 mm
179.92 in.
Width 1710 mm
67.32 in.
Height 1500 mm
59.06 in.
Wheelbase 2630 mm
103.54 in.
Front track 1480 mm
58.27 in.
Rear (Back) track 1450 mm
57.09 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Spring Strut
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 185/65 R14
