Specifications: Toyota C-HR I (facelift 2020) 1.2 (116 Hp) 2020, 2021, 2022, 2023

2020 Toyota C-HR I (facelift 2020) - Photo 1

Toyota C-HR I (facelift 2020) 1.2 (116 Hp) – Full specifications
General information
Brand Toyota
Model C-HR
Generation C-HR I (facelift 2020)
Modification (Engine) 1.2 (116 Hp)
Start of production 2020 year
End of production June, 2023 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.3-7.6 l/100 km
32.22 – 30.95 US mpg
38.7 – 37.17 UK mpg
13.7 – 13.16 km/l
Fuel consumption (economy) – extra urban 5.3 l/100 km
44.38 US mpg
53.3 UK mpg
18.87 km/l
Fuel consumption (economy) – combined 6.1-6.2 l/100 km
38.56 – 37.94 US mpg
46.31 – 45.56 UK mpg
16.39 – 16.13 km/l
CO2 emissions 138 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.9 sec
Acceleration 0 – 62 mph 10.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.4 sec
Maximum speed 190 km/h
118.06 mph
Emission standard Euro 6
Weight-to-power ratio 11.9 kg/Hp, 84.4 Hp/tonne
Weight-to-torque ratio 7.4 kg/Nm, 134.5 Nm/tonne
Engine specs
Power 116 Hp @ 5200-5600 rpm.
Power per litre 96.9 Hp/l
Torque 185 Nm @ 1500-4000 rpm.
136.45 lb.-ft. @ 1500-4000 rpm.
Engine layout Front, Transverse
Engine Model/Code 8NR-FTS
Engine displacement 1197 cm3
73.05 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 71.5 mm
2.81 in.
Piston Stroke 74.5 mm
2.93 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC, Dual VVT-iW
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.4 l
6.76 US qt | 5.63 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1375-1435 kg
3031.36 – 3163.63 lbs.
Max. weight 1845 kg
4067.53 lbs.
Max load 410-470 kg
903.9 – 1036.17 lbs.
Trunk (boot) space – minimum 377 l
13.31 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Permitted trailer load with brakes (12%) 1300 kg
2866.01 lbs.
Permitted trailer load without brakes 730 kg
1609.37 lbs.
Dimensions
Length 4390 mm
172.83 in.
Width 1795 mm
70.67 in.
Height 1565 mm
61.61 in.
Wheelbase 2640 mm
103.94 in.
Front track 1540-1550 mm
60.63 – 61.02 in.
Rear (Back) track 1550-1560 mm
61.02 – 61.42 in.
Front overhang 935 mm
36.81 in.
Rear overhang 815 mm
32.09 in.
Drag coefficient (Cd) 0.33
Minimum turning circle (turning diameter) 11.0 m
36.09 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Double wishbone
Front brakes Ventilated discs, 298 mm
Rear brakes Disc, 281 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/60 R17 96H; 225/50 R18 95H
Wheel rims size 17; 18
