| General information | |
|---|---|
| Brand | Toyota |
| Model | Caldina |
| Generation | Caldina (T19) |
| Modification (Engine) | 2.0 i 16V TZ (133 Hp) |
| Start of production | 1992 year |
| End of production | 1997 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – combined | 6.5 l/100 km 36.19 US mpg 43.46 UK mpg 15.38 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 9.3 kg/Hp, 107.3 Hp/tonne |
| Weight-to-torque ratio | 6.8 kg/Nm, 147.6 Nm/tonne |
| Engine specs | |
| Power | 133 Hp @ 5800 rpm. |
| Power per litre | 66.6 Hp/l |
| Torque | 183 Nm @ 4400 rpm. 134.97 lb.-ft. @ 4400 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 3S-GE |
| Engine displacement | 1998 cm3 121.93 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm 3.39 in. |
| Piston Stroke | 86 mm 3.39 in. |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.5 l 4.76 US qt | 3.96 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.6 l 6.97 US qt | 5.81 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1240 kg 2733.73 lbs. |
| Max. weight | 1515 kg 3340 lbs. |
| Max load | 275 kg 606.27 lbs. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Dimensions | |
| Length | 4545 mm 178.94 in. |
| Width | 1695 mm 66.73 in. |
| Height | 1450 mm 57.09 in. |
| Wheelbase | 2580 mm 101.57 in. |
| Front track | 1465 mm 57.68 in. |
| Rear (Back) track | 1450 mm 57.09 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Spring Strut |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 185/65 R14 S |
