Specifications: Toyota Camry III Wagon (XV10) 2.2 (136 Hp) Automatic 1992, 1993, 1994, 1995, 1996

1992 Toyota Camry III Wagon (XV10) - Photo 1

Toyota Camry III Wagon (XV10) 2.2 (136 Hp) Automatic – Full specifications
General information
Brand Toyota
Model Camry
Generation Camry III Wagon (XV10)
Modification (Engine) 2.2 (136 Hp) Automatic
Start of production 1992 year
End of production 1996 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – combined 9.2 l/100 km
25.57 US mpg
30.7 UK mpg
10.87 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.5 sec
Acceleration 0 – 62 mph 12.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.9 sec
Maximum speed 185 km/h
114.95 mph
Weight-to-power ratio 10.5 kg/Hp, 95.3 Hp/tonne
Weight-to-torque ratio 7.3 kg/Nm, 137.4 Nm/tonne
Engine specs
Power 136 Hp @ 5400 rpm.
Power per litre 62.8 Hp/l
Torque 196 Nm @ 4200 rpm.
144.56 lb.-ft. @ 4200 rpm.
Engine layout Front, Transverse
Engine Model/Code 5S-FE
Engine displacement 2164 cm3
132.06 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 87.1 mm
3.43 in.
Piston Stroke 90.9 mm
3.58 in.
Compression ratio 9.7:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.6 l
3.8 US qt | 3.17 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt

Space, Volume and weights
Kerb Weight 1427 kg
3146 lbs.
Max. weight 2105 kg
4640.73 lbs.
Max load 678 kg
1494.73 lbs.
Trunk (boot) space – minimum 533 l
18.82 cu. ft.
Trunk (boot) space – maximum 843 l
29.77 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4795 mm
188.78 in.
Width 1770 mm
69.69 in.
Height 1490 mm
58.66 in.
Wheelbase 2620 mm
103.15 in.
Front track 1545 mm
60.83 in.
Rear (Back) track 1490 mm
58.66 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/65 R15
Wheel rims size 15
