Specifications: Toyota Camry VI (XV40) 3.5i V6 (268 Hp) Automatic 2006, 2007, 2008, 2009

2007 Toyota Camry VI (XV40) - Photo 1

Toyota Camry VI (XV40) 3.5i V6 (268 Hp) Automatic – Full specifications
General information
Brand Toyota
Model Camry
Generation Camry VI (XV40)
Modification (Engine) 3.5i V6 (268 Hp) Automatic
Start of production 2006 year
End of production 2009 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 10.7 l/100 km
21.98 US mpg
26.4 UK mpg
9.35 km/l
Fuel consumption (economy) – extra urban 7 l/100 km
33.6 US mpg
40.35 UK mpg
14.29 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 5.9 kg/Hp, 170.7 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 214 Nm/tonne
Engine specs
Power 268 Hp @ 6200 rpm.
Power per litre 77.5 Hp/l
Torque 336 Nm @ 4700 rpm.
247.82 lb.-ft. @ 4700 rpm.
Engine layout Front, Transverse
Engine Model/Code 2GR-FE
Engine displacement 3456 cm3
210.9 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 94 mm
3.7 in.
Piston Stroke 83 mm
3.27 in.
Compression ratio 10.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, VVT-i
Engine oil capacity 6.1 l
6.45 US qt | 5.37 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9 l
9.51 US qt | 7.92 UK qt

Space, Volume and weights
Kerb Weight 1570-1595 kg
3461.26 – 3516.37 lbs.
Max. weight 2028 kg
4470.97 lbs.
Max load 433-458 kg
954.6 – 1009.72 lbs.
Trunk (boot) space – minimum 425 l
15.01 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4805 mm
189.17 in.
Width 1820 mm
71.65 in.
Height 1460 mm
57.48 in.
Wheelbase 2775 mm
109.25 in.
Front track 1575 mm
62.01 in.
Rear (Back) track 1565 mm
61.61 in.
Minimum turning circle (turning diameter) 11 m
36.09 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/60 R16; 215/55 R17
Wheel rims size 16; 17
