Specifications: Toyota Corolla Cross (facelift 2024) 2.0 (196 Hp) Hybrid AWD e-CVT 2025

2024 Toyota Corolla Cross (facelift 2024) - Photo 1

Toyota Corolla Cross (facelift 2024) 2.0 (196 Hp) Hybrid AWD e-CVT – Full specifications
General information
Brand Toyota
Model Corolla Cross
Generation Corolla Cross (facelift 2024)
Modification (Engine) 2.0 (196 Hp) Hybrid AWD e-CVT
Start of production September, 2025 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.2 l/100 km
45.23 US mpg
54.32 UK mpg
19.23 km/l
Fuel consumption (economy) – extra urban 6.2 l/100 km
37.94 US mpg
45.56 UK mpg
16.13 km/l
Fuel consumption (economy) – combined 5.6 l/100 km
42 US mpg
50.44 UK mpg
17.86 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 60 mph 8 sec
Emission standard SULEV 30
Weight-to-power ratio 7.7 kg/Hp, 129.8 Hp/tonne
Weight-to-torque ratio 8 kg/Nm, 124.5 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 0.9 kWh
Battery voltage 222 V
Battery technology Lithium-ion (Li-Ion)
Electric motor 1
Electric motor location Integrated into the transmission
Electric motor type Synchronous
Electric motor 2
Electric motor location Rear axle, Transverse
System power 196 Hp
Internal combustion engine specs
Power 150 Hp @ 6000 rpm.
Power per litre 75.5 Hp/l
Torque 188 Nm @ 4400-5200 rpm.
138.66 lb.-ft. @ 4400-5200 rpm.
Engine layout Front, Transverse
Engine Model/Code Dynamic Force
Engine displacement 1987 cm3
121.25 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80.5 mm
3.17 in.
Piston Stroke 97.6 mm
3.84 in.
Compression ratio 14:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, Dual VVT-i
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1510-1556 kg
3328.98 – 3430.39 lbs.
Max. weight 2086 kg
4598.84 lbs.
Max load 530-576 kg
1168.45 – 1269.86 lbs.
Trunk (boot) space – minimum 481 l
16.99 cu. ft.
Trunk (boot) space – maximum 1246 l
44 cu. ft.
Fuel tank capacity 40 l
10.57 US gal | 8.8 UK gal
Permitted trailer load with brakes (12%) 680 kg
1499.14 lbs.
Permitted towbar download 68 kg
149.91 lbs.
Dimensions
Length 4490 mm
176.77 in.
Width 1825 mm
71.85 in.
Height 1648 mm
64.88 in.
Wheelbase 2640 mm
103.94 in.
Front track 1557 mm
61.3 in.
Rear (Back) track 1557 mm
61.3 in.
Ride height (ground clearance) 204 mm
8.03 in.
Minimum turning circle (turning diameter) 10.8 m
35.43 ft.
Approach angle 16.2°
Departure angle 22.8°
Drivetrain, brakes and suspension specs
Drivetrain Architecture An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox automatic transmission e-CVT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Double wishbone, Independent coil spring, Transverse stabilizer
Front brakes Ventilated discs, 305 mm
Rear brakes Disc, 282 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/65 R17; 225/55 R18
Wheel rims size 17; 18
