Specifications: Toyota Corolla Spacio I (E110) 1.8i (125 Hp) Automatic 2000, 2001

1997 Toyota Corolla Spacio I (E110) - Photo 1

Toyota Corolla Spacio I (E110) 1.8i (125 Hp) Automatic – Full specifications
General information
Brand Toyota
Model Corolla Spacio
Generation Corolla Spacio I (E110)
Modification (Engine) 1.8i (125 Hp) Automatic
Start of production 2000 year
End of production 2001 year
Powertrain Architecture Internal Combustion engine
Body type MPV
Seats 5
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Engine specs
Power 125 Hp @ 6000 rpm.
Power per litre 69.7 Hp/l
Torque 161 Nm @ 4200 rpm.
118.75 lb.-ft. @ 4200 rpm.
Engine layout Front, Transverse
Engine Model/Code 1ZZ-FE
Engine displacement 1794 cm3
109.48 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79 mm
3.11 in.
Piston Stroke 91.5 mm
3.6 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.7 l
3.91 US qt | 3.26 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt

Space, Volume and weights
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Dimensions
Length 4135 mm
162.8 in.
Width 1690 mm
66.54 in.
Height 1620 mm
63.78 in.
Wheelbase 2260 mm
88.98 in.
Front track 1460 mm
57.48 in.
Rear (Back) track 1450 mm
57.09 in.
Minimum turning circle (turning diameter) 10 m
32.81 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Front brakes Ventilated discs
Rear brakes Drum
Tires size 185/65 R14
Wheel rims size 14
