| General information | |
|---|---|
| Brand | Toyota |
| Model | Corolla Verso |
| Generation | Corolla Verso II (AR10) |
| Modification (Engine) | 2.2 D-4D (136 Hp) DPF 7 Seats |
| Start of production | 2004 year |
| End of production | 2007 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | MPV |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 8.3 l/100 km 28.34 US mpg 34.03 UK mpg 12.05 km/l |
| Fuel consumption (economy) – extra urban | 5.6 l/100 km 42 US mpg 50.44 UK mpg 17.86 km/l |
| Fuel consumption (economy) – combined | 6.6 l/100 km 35.64 US mpg 42.8 UK mpg 15.15 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 10.2 sec |
| Acceleration 0 – 62 mph | 10.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.7 sec |
| Maximum speed | 195 km/h 121.17 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 11.6 kg/Hp, 86.3 Hp/tonne |
| Weight-to-torque ratio | 5.1 kg/Nm, 196.8 Nm/tonne |
| Engine specs | |
| Power | 136 Hp @ 3600 rpm. |
| Power per litre | 61 Hp/l |
| Torque | 310 Nm @ 2000 rpm. 228.64 lb.-ft. @ 2000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 2AD-FTV |
| Engine displacement | 2231 cm3 136.14 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm 3.39 in. |
| Piston Stroke | 96 mm 3.78 in. |
| Compression ratio | 16.8:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.9 l 6.23 US qt | 5.19 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8 l 8.45 US qt | 7.04 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1575 kg 3472.28 lbs. |
| Max. weight | 2140 kg 4717.89 lbs. |
| Max load | 565 kg 1245.61 lbs. |
| Trunk (boot) space – minimum | 620 l 21.9 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Dimensions | |
| Length | 4370 mm 172.05 in. |
| Width | 1770 mm 69.69 in. |
| Height | 1620 mm 63.78 in. |
| Wheelbase | 2750 mm 108.27 in. |
| Front track | 1480 mm 58.27 in. |
| Rear (Back) track | 1490 mm 58.66 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/55 R16 |
