1988 Toyota Corolla  Wagon VI (E90) - Photo 1

Toyota Corolla Wagon VI (E90) 1.6 XLI (AE95) (105 Hp) 4×4 – Full specifications

General information
Brand Toyota
Model Corolla
Generation Corolla Wagon VI (E90)
Modification (Engine) 1.6 XLI (AE95) (105 Hp) 4×4
Start of production 1988 year
End of production 1992 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Maximum speed 172 km/h
106.88 mph
Weight-to-power ratio 11.2 kg/Hp, 89 Hp/tonne
Engine specs
Power 105 Hp @ 5000 rpm.
Power per litre 65.6 Hp/l
Engine layout Front, Longitudinal
Engine Model/Code 4A-F
Engine displacement 1600 cm3
97.64 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Supercharger
Engine oil capacity 3.2 l
3.38 US qt | 2.82 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.6 l
5.92 US qt | 4.93 UK qt

Space, Volume and weights
Kerb Weight 1180 kg
2601.45 lbs.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Drum
Power steering Hydraulic Steering
