Specifications: Toyota Corolla XII (E210, facelift 2022) 1.8 (140 Hp) Hybrid e-CVT 2023, 2024, 2025

2023 Toyota Corolla XII (E210, facelift 2022) - Photo 1

Toyota Corolla XII (E210, facelift 2022) 1.8 (140 Hp) Hybrid e-CVT – Full specifications
General information
Brand Toyota
Model Corolla
Generation Corolla XII (E210, facelift 2022)
Modification (Engine) 1.8 (140 Hp) Hybrid e-CVT
Start of production 2023 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body type Sedan
Seats 5
Doors 4
Performance specs
Combined fuel consumption (WLTP) 4.1 l/100 km
57.37 US mpg
68.9 UK mpg
24.39 km/l
CO2 emissions (WLTP) 93 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.3 sec
Acceleration 0 – 62 mph 9.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.8 sec
Maximum speed 180 km/h
111.85 mph
Emission standard Euro 6 AG
Weight-to-power ratio 9.6 kg/Hp, 104.5 Hp/tonne
Weight-to-torque ratio 9.4 kg/Nm, 106 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 0.85 kWh
Battery voltage 207.2 V
Battery technology Lithium-ion (Li-Ion)
Battery location Under the rear seats
Electric motor 1
Electric motor power 95 Hp
Electric motor Torque 185 Nm

136.45 lb.-ft.
Electric motor location Integrated into the transmission
Electric motor type Synchronous
System power 140 Hp
Internal combustion engine specs
Power 97 Hp @ 5200 rpm.
Power per litre 53.9 Hp/l
Torque 142 Nm @ 3600 rpm.
104.73 lb.-ft. @ 3600 rpm.
Engine layout Front, Transverse
Engine Model/Code 2ZR-FXE
Engine displacement 1798 cm3
109.72 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80.5 mm
3.17 in.
Piston Stroke 88.3 mm
3.48 in.
Compression ratio 13:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.4 l
5.71 US qt | 4.75 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1340-1385 kg
2954.19 – 3053.4 lbs.
Trunk (boot) space – minimum 471 l
16.63 cu. ft.
Fuel tank capacity 43 l
11.36 US gal | 9.46 UK gal
Permitted trailer load with brakes (12%) 750 kg
1653.47 lbs.
Permitted trailer load without brakes 450 kg
992.08 lbs.
Dimensions
Length 4630 mm
182.28 in.
Width 1780 mm
70.08 in.
Height 1435 mm
56.5 in.
Wheelbase 2700 mm
106.3 in.
Front track 1531 mm
60.28 in.
Rear (Back) track 1544 mm
60.79 in.
Front overhang 935 mm
36.81 in.
Rear overhang 995 mm
39.17 in.
Ride height (ground clearance) 130 mm
5.12 in.
Minimum turning circle (turning diameter) 10.4 m
34.12 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission e-CVT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16
Wheel rims size 7J x 16
