Specifications: Toyota Corsa Hatchback (L40) 1.5 i (105 Hp) 1990, 1991, 1992, 1993, 1994

Toyota Corsa Hatchback (L40) 1.5 i (105 Hp) – Full specifications
General information
Brand Toyota
Model Corsa
Generation Corsa Hatchback (L40)
Modification (Engine) 1.5 i (105 Hp)
Start of production 1990 year
End of production 1994 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 7.5 l/100 km
31.36 US mpg
37.66 UK mpg
13.33 km/l
Fuel consumption (economy) – extra urban 4.2 l/100 km
56 US mpg
67.26 UK mpg
23.81 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 8 kg/Hp, 125 Hp/tonne
Weight-to-torque ratio 6.6 kg/Nm, 151.2 Nm/tonne
Engine specs
Power 105 Hp @ 6400 rpm.
Power per litre 70.1 Hp/l
Torque 127 Nm @ 3200 rpm.
93.67 lb.-ft. @ 3200 rpm.
Engine layout Front, Transverse
Engine Model/Code 5E-FE
Engine displacement 1497 cm3
91.35 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 74 mm
2.91 in.
Piston Stroke 87 mm
3.43 in.
Compression ratio 9.4:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.2 l
3.38 US qt | 2.82 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 840 kg
1851.88 lbs.
Dimensions
Length 3930 mm
154.72 in.
Width 1645 mm
64.76 in.
Height 1365 mm
53.74 in.
Wheelbase 2380 mm
93.7 in.
Front track 1400 mm
55.12 in.
Rear (Back) track 1430 mm
56.3 in.
Minimum turning circle (turning diameter) 9 m
29.53 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Tires size 155/80 SR13
