| General information | |
|---|---|
| Brand | Toyota |
| Model | Crown |
| Generation | Crown XIV Athlete (S210, facelift 2016) |
| Modification (Engine) | 3.5 V6 24V (315 Hp) ECT |
| Start of production | 2016 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 5.2 kg/Hp, 193.3 Hp/tonne |
| Weight-to-torque ratio | 4.3 kg/Nm, 231.3 Nm/tonne |
| Engine specs | |
| Power | 315 Hp @ 6400 rpm. |
| Power per litre | 91.1 Hp/l |
| Torque | 377 Nm @ 4800 rpm. 278.06 lb.-ft. @ 4800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | 2GR-FSE |
| Engine displacement | 3456 cm3 210.9 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 94 mm 3.7 in. |
| Piston Stroke | 83 mm 3.27 in. |
| Compression ratio | 11.8:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 6.4 l 6.76 US qt | 5.63 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9.8 l 10.36 US qt | 8.62 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1630 kg 3593.53 lbs. |
| Max. weight | 1905 kg 4199.81 lbs. |
| Max load | 275 kg 606.27 lbs. |
| Fuel tank capacity | 71 l 18.76 US gal | 15.62 UK gal |
| Dimensions | |
| Length | 4895 mm 192.72 in. |
| Width | 1800 mm 70.87 in. |
| Height | 1450 mm 57.09 in. |
| Wheelbase | 2850 mm 112.2 in. |
| Front track | 1545 mm 60.83 in. |
| Rear (Back) track | 1545 mm 60.83 in. |
| Ride height (ground clearance) | 135 mm 5.31 in. |
| Minimum turning circle (turning diameter) | 10.4 m 34.12 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission Super ECT |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 225/45 R18 |
| Wheel rims size | 18 |
