Specifications: Toyota Kluger III 3.5 V6 (273 Hp) Automatic 2013, 2014, 2015, 2016

2014 Toyota Kluger III - Photo 1

Toyota Kluger III 3.5 V6 (273 Hp) Automatic – Full specifications
General information
Brand Toyota
Model Kluger
Generation Kluger III
Modification (Engine) 3.5 V6 (273 Hp) Automatic
Start of production December, 2013 year
End of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – combined 10.2 l/100 km
23.06 US mpg
27.69 UK mpg
9.8 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 7.1 kg/Hp, 141.1 Hp/tonne
Weight-to-torque ratio 5.7 kg/Nm, 174.2 Nm/tonne
Engine specs
Power 273 Hp @ 6200 rpm.
Power per litre 79 Hp/l
Torque 337 Nm @ 4700 rpm.
248.56 lb.-ft. @ 4700 rpm.
Engine layout Front, Transverse
Engine Model/Code 2GR-FE
Engine displacement 3456 cm3
210.9 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 94 mm
3.7 in.
Piston Stroke 83 mm
3.27 in.
Compression ratio 10.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, D-VVT-i
Engine oil capacity 6.1 l
6.45 US qt | 5.37 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.2 l
11.83 US qt | 9.85 UK qt

Space, Volume and weights
Kerb Weight 1935-1995 kg
4265.94 – 4398.22 lbs.
Max. weight 2670 kg
5886.34 lbs.
Max load 675-735 kg
1488.12 – 1620.4 lbs.
Trunk (boot) space – minimum 529 l
18.68 cu. ft.
Fuel tank capacity 72 l
19.02 US gal | 15.84 UK gal
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Dimensions
Length 4685 mm
184.45 in.
Width 1925 mm
75.79 in.
Height 1730 mm
68.11 in.
Wheelbase 2790 mm
109.84 in.
Ride height (ground clearance) 200.3 mm
7.89 in.
Minimum turning circle (turning diameter) 11.8 m
38.71 ft.
Approach angle 18.0°
Departure angle 23.1°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent type McPherson
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Wheel rims size 18; 19
